The ASRock Phantom Gaming B860I Lightning WiFi motherboard is designed for gamers and builders looking for a compact yet powerful solution. With an Intel B860 chipset and support for Intel Core Ultra processors, this mini ITX motherboard provides robust performance and advanced capabilities. It is equipped with dual-channel DDR5 SDRAM support at speeds up to 9333 MHz overclocking, ensuring efficient data handling for intensive applications and gaming sessions. The B860I Lightning WiFi offers extensive connectivity options, including multiple USB ports, HDMI, and dual LAN featuring a 2.5 Gigabit Ethernet connection. Enhanced audio quality is achieved with the Realtek ALC1220 codec, delivering high definition audio across channels. With its user-friendly features like UEFI BIOS and ASRock Instant Flash, building and configuring systems is simple and intuitive, perfect for novice and veteran users alike.
| Series - Mainboards | ||
| series | AsRock PHANTOM Series | |
| Basic motherboard characteristics | ||
| Manufacturer | ASRock | |
| Chipset | Intel® B860 | |
| Form factor | Mini-ITX | |
| Motherboard processor | ||
| Processor family | Intel | |
| processor socket | Base 1851 | |
| Supported processors | Intel Core Ultra 200 (Arrow Lake-S) | |
| Motherboard memory | ||
| Number of DIMM slots | 2x | |
| Maximum main memory | 128 GB | |
| Storage type | DDR5 | |
| supported memory clock | max. DDR5-9333 OC | |
| Motherboard expansion slots | ||
| PCI-Express x16 (total) | 1x | |
| PCI-Express 5.0 x16 | 1x | |
| M.2 | 2x | |
| Motherboard External Connectors | ||
| HDMI | 1x | |
| USB 4.0 | 1x (Thunderbolt) | |
| USB 3.2 Type-C | 1x | |
| USB 3.1 Type-A | 2x | |
| USB 3.0 | 4x | |
| USB 2.0 | 1x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 2x | |
| Toslink/S/PDIF (optical) | Yes | |
| Internal motherboard connectors | ||
| SATA 6 GB/s | 3x | |
| USB 3.1 Header | 1x (Type-C) | |
| USB 3.0 Header | 1 x | |
| USB 2.0 Header | 1 x | |
| TPM header | Yes | |
| RAID | 0/1/5/10 | |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V | |
| Audio codec | Realtek ALC1220 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 1x | |
| 4-pin case fan | 1x | |
| 4-pin pump | 1x | |
| Thermal sensor | 1x | |
| Motherboard lighting | ||
| ARGB 3-pin header | 2x | |
| Lighting color | RGB | |
| Motherboard network | ||
| LAN Controller | (2.5GBase-T, Realtek RTL8125BG) | |
| Transfer rate | 10/100/1000/2500 Mb/s | |
| Wi-Fi | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.3 | |
| Motherboard features | ||
| Integrated I/O shield | Yes | |
| Audio + solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
