The GIGABYTE AORUS X870 ELITE X3D ICE is designed to elevate the performance of any gaming rig or high-performance workstation. With support for AMD Ryzen processors and a robust AMD X870 chipset, this motherboard offers excellent multitasking capabilities, power management, and advanced cooling features that cater to demanding users. The motherboard supports DDR5 RAM with speeds up to 9000 MT/s (O.C.), ensuring that programs and games run smoothly. Multiple expansion slots, including PCIe 5.0 x16 and M.2 slots, provide flexibility for high-speed storage and additional graphics cards, while the custom cooling solutions ensure stable operation under load. High definition audio and a variety of connectivity options ensure an immersive multimedia experience, making it a solid choice for enthusiasts and professionals alike. This motherboard provides the framework for a powerful computing experience, built with durability and longevity in mind.
| Series - Mainboards | ||
| series | Gigabyte AORUS Elite | |
| Basic motherboard characteristics | ||
| Chipset manufacturer | AMD | |
| Manufacturer | GIGABYTE | |
| Chipset | AMD X870 | |
| Form factor | ATX | |
| BIOS type | 1x 64MB (512Mb) | |
| Dimensions | (ATX) 305 mm × 244 mm | |
| Motherboard processor | ||
| Processor family | AMD | |
| processor socket | Socket AM5 | |
| Supported processors | Ryzen 9000, Ryzen 8000G, Ryzen 7000 | |
| Motherboard memory | ||
| Number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| Storage type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| supported memory clock | up to 9000 MHz | |
| Motherboard expansion slots | ||
| PCI-Express x16 (total) | 2x | |
| PCI-Express 5.0 x16 | 1x | |
| PCI-Express 4.0 x16 | 1x | |
| M.2 | 4x | |
| Motherboard External Connectors | ||
| HDMI | 1x | |
| USB 4.0 | 2x (with DisplayPort 1.4a) | |
| USB 3.1 Type-A | 2x | |
| USB 3.1 Type-C | 1x | |
| USB 3.0 | 4x | |
| USB 2.0 | 1x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 2x | |
| Toslink/S/PDIF (optical) | Yes | |
| Internal motherboard connectors | ||
| SATA 6 GB/s | 2x | |
| USB 3.2 Header | 1x | |
| USB 3.0 Header | 2 x | |
| USB 2.0 Header | 2 x | |
| RAID | 0/1/10 | |
| Power connections | 1x 24-pin ATX, 2x 8-pin EPS12V | |
| Audio channels | 7.1 | |
| Audio codec | Realtek ALC1220 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 1x | |
| 4-pin case fan | 4x | |
| 4-pin pump | 3x | |
| Thermal sensor | 2x | |
| Special features | 1x Noise Sensor Header | |
| Motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB 3-pin header | 3x | |
| Lighting color | RGB | |
| LED compatibility | Gigabyte RGB Fusion 2.0 | |
| Motherboard network | ||
| LAN Controller | 1x RJ-45 (5GBase-T, Realtek) | |
| Transfer rate | 10/100/1000/2500/5000 Mb/s | |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) | |
| Bluetooth | 5.4 | |
| Motherboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 4x | |
| Diagnostic LED | Yes | |
| Display | Yes | |
| Integrated I/O shield | Yes | |
| Audio + solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
