The ASRock B850M Pro RS WiFi motherboard is designed for performance and connectivity, tailored for the next generation of computing. This micro ATX motherboard is compatible with Ryzen processors and features a Socket AM5, making it an ideal choice for building powerful systems. With support for DDR5 SDRAM and speeds up to 8000 MHz (O.C.), users can experience enhanced performance for demanding applications. The motherboard also offers extensive storage options, including multiple M.2 sockets and SATA connections, ensuring ample space for high-speed data transfer. Networking capabilities are robust, incorporating 2.5 Gigabit Ethernet and Wi-Fi 6E support for fast and reliable Internet connectivity. The inclusion of Bluetooth 5.2 adds flexibility in connecting wireless devices. An advanced audio output system featuring high definition audio and a Realtek ALC897 codec delivers sound quality for gaming, entertainment, and productivity. This motherboard is a solid foundation for building a responsive and high-functioning PC.
| Series - Motherboards | ||
| series | Asrock PRO Series | |
| Mainboard basic features | ||
| Manufacturer | ASRock | |
| Chipset | AMD B850 | |
| Form factor | Micro-ATX | |
| Motherboard processor | ||
| Processor family | AMD | |
| Processor socket | Socket AM5 | |
| Supported processors | Ryzen 9000, Ryzen 8000G, Ryzen 7000 | |
| Motherboard memory | ||
| Number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| Memory type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| Motherboard expansion slots | ||
| PCI Express x16 (total) | 1x | |
| PCI Express 5.0 x16 | 1x | |
| PCI Express x4 | 1x | |
| M.2 | 3x | |
| Mainboard external connections | ||
| DisplayPort | Yes | |
| HDMI | Yes | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 3x | |
| Motherboard internal connections | ||
| SATA 6 GB/s | 4x | |
| USB 3.0 header | 3 times | |
| USB 2.0 header | 2 x | |
| TPM header | Yes | |
| other | 1x speaker header | |
| RAID | 0/1/10 | |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V | |
| Audio channels | 7.1 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 2x | |
| 4-pin case fan | 3x | |
| Motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB header 3-pin | 3x | |
| Mainboard network | ||
| LAN controller | 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG) | |
| Transfer rate | 10/100/1000/2500 Mbps | |
| Wi-Fi | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.2 | |
| Mainboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 1x | |
| Diagnostic LED | Yes | |
| Integrated IO panel | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
