Chipset: AMD B550 / Processor socket: Socket AM4 / Memory support: 4x DDR4 / Form factor: ATX
| series - motherboards | ||
| series | AsRock PHANTOM series | |
| motherboard basic properties | ||
| Manufacturer | ASRock | |
| chipset | AMD B550 | |
| form factor | ATX | |
| Dimensions | (ATX) 305 mm × 244 mm | |
| motherboard processor | ||
| processor family | AMD | |
| processor socket | Socket AM4 | |
| Supported processors | Ryzen 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series desktop processors | |
| motherboard memory | ||
| number of DIMM slots | 4x | |
| Maximum main memory | 128 GB | |
| storage type | DDR4 | |
| Non-ECC, Un-buffered | Yes | |
| motherboard expansion slots | ||
| PCI-Express x16 (total) | 3x | |
| PCI-Express x1 | 1x (3.0) | |
| M.2 | 3x | |
| motherboard external connections | ||
| HDMI | Yes | |
| USB 3.2 Type-C | 1x | |
| USB 3.2 Type A | 7x | |
| USB 2.0 | 2x | |
| PS/2 | 1 x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 6x | |
| Toslink/S/PDIF (optical) | Yes | |
| motherboard internal connections | ||
| SATA 6 GB/s | 6x | |
| USB 3.2 header | 2x | |
| USB 2.0 header | 3 x | |
| Thunderbolt 2 AIC (5-pin header) | Yes | |
| TPM header | Yes | |
| RAID | 0/1/10 | |
| power connections | 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V | |
| audio channels | 7.1 | |
| audio codec | ALC897 | |
| audio features | Nahimic Audio | |
| motherboard cooling | ||
| CPU fan 4-pin | 1x | |
| case fan 4-pin | 5x | |
| pump 4-pin | 1x | |
| motherboard lighting | ||
| RGB header 4-pin | 2x | |
| motherboard network | ||
| LAN controller | Killer E3100G | |
| transfer rate | 10/100/1000/2500 Mb/s | |
| motherboard features | ||
| IO panel integrated | Yes | |
| Condition | ||
| item condition | New | |
