Logitech Rally Bar + Tap IP - 4K Ultra HD - 30 fps - 5x - 3x - Graphite

Services
Product color: Graphite
Swivel range: -25° - 25°
Tilt angle range: -15° - 15°
PTZ control: Yes
video
HD type: 4K Ultra HD
Maximum video resolution: 3840 x 2160 pixels
Supported video modes: 576p, 720p, 900p, 1440p, 2160p
Maximum frame rate: 30 fps
Audio
Built-in speakers: Yes
Output level: 92/99 dB
Line-out impedance: 4 ohms
Output voltage Total harmonic distortion (THD): 2%
Audio beamforming: Yes
Noise cancellation: Yes
Echo cancellation: Yes
RMS power: 8 W
Microphone reception range: 4.5 m
Sampling rates: 0 - 48 kHz
Driver diameter: 7 cm
Connections and interfaces
Number of HDMI ports: 3
Number of HDMI output ports: 2
Number of HDMI input interfaces: 1
USB connectors: USB Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 3
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports: 1
Number of Ethernet LAN ports (RJ-45): 1
Direct current (DC) connection: Yes
Interface module
Interface module Number of RJ45 ports: 1
network
Ethernet/LAN: Yes
Ethernet LAN data transfer rates: 10, 100, 1000 Mbit/s
Wi-Fi: Yes
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Supported network protocols: IPv4, IPv6
Supported security algorithms: 128-bit AES
camera
Zoom capability: Yes
Optical zoom: 5x
Digital zoom: 3x
Combined zoom: 15x
Horizontal field of view: 82.1°
Vertical field of view: 52.2°
Diagonal field of view: 90°
Remote control interface: Bluetooth
Screen
Display: IPS
Screen diagonal: 25.6 cm (10.1“)
Display resolution: 1280 x 800 pixels
Contrast ratio: 1000:1
Touchscreen: Yes
Touch screen type: Capacitive
Horizontal viewing angle: 85°
Vertical viewing angle: 85°
Brightness: 400 cd/m²
Grease-resistant coating: Yes
microphone
Microphone sensitivity: -36 dB
Microphone frequency: 90 - 16000 Hz
Integrated microphone orientation: Omnidirectional
Sound pressure level (max): 90 dB
Number of microphones: 6
Features
Telepresence: No
Motion sensor: Yes
Cable lock slot: Yes
Cable lock slot type: Kensington
Logistics data
Shipping carton weight: 13 kg
Length of shipping carton: 1013 mm
Shipping carton width: 270 mm
Shipping carton height: 327 mm
computer system
Supports Windows operating systems: Yes
Supported Mac operating systems: MacOS
System requirements
Minimum system requirements: Internet connection: Wired or wireless (Rally Bar without a wireless remote supports Wi-Fi connections). USB mode: Windows 11, Windows 10, the two latest versions of macOS. Appliance mode: Software license for room solution software (not included).
Operating conditions
Operating temperature: 0 - 40 °C
Relative humidity during operation: 10 - 95%
Storage temperature range: -40 - 70 °C
Heat dissipation: 64 BTU/h
energy
Energy source: AC
AC input voltage: 100 - 240 V
Current: 4.74 A
DC input voltage: 19 V
Battery technology: Lithium
Battery/Battery Capacity: 220mAh
Number of supported batteries/accumulators: 1
Power plug type: Type C
Weight and dimensions
Interface module dimensions (W x H x D): 246.2 x 171.3 x 56.1 mm
Interface module weight: 1 kg
Width: 910 mm
Depth: 160 mm
Height: 164 mm
Weight: 7.08 kg
Packaging data
Packaging width: 264 mm
Packaging depth: 1007 mm
Packaging height: 314 mm
Package weight: 13 kg
Scope of delivery
Power cable length: 1.5 m
HDMI cable length: 2 m
AC power adapter: Yes
Mounting kit: Yes
Remote control included: Yes
Camera included: Yes
Batteries/accumulators included: Yes
Quick Start Overview: Yes
Package contents: Logitech Rally Bar Videobar, Rally Bar power supply, cable, lens covers, remote control, user manual, Logitech Tap IP touch controller, Tap IP VESA mounting screws (4), microfiber cloth, documentation
