Digitus 4K HDMI KVM Extender Set, 70 m, Transmitter and Receiver, 70 m, Cat6, Cat7, Cat8, Black, Aluminum. Digitus 4K HDMI KVM Extender Set, 70 m. Type: Transmitter and Receiver, Maximum possible transmission distance: 70 m, Supported cable types: Cat6, Cat7, Cat8. Transmitter video connection type: HDMI. Receiver local video connection type: HDMI, Receiver local keyboard/mouse connection type: USB. USB port type: Mini-USB A. Power supply output voltage: 5 V, AC adapter output current: 2 A, Power consumption (transmitter) (max.): 4 W
Podijelite:
Extends an HDMI signal to a distance of up to 70 m in UHD resolution (4K/60Hz) and offers KVM/USB functionality for connecting a mouse, keyboard and touchscreen.
- Supports 4K2K/60Hz (HDR, 4:4:4)
- Video bandwidth: 18 Gbps
- Maximum transmission distance (UHD 4K2K): 70 m
- KVM/USB functionality - Connection of mouse, keyboard, touchscreen
- HDMI loop-out on the transmitter unit
- Supports CAT 6/7/8 cables
- Audio extractor on the receiver unit (S/PDIF)
- EDID Pass Back
- HDCP 2.2 / 1.4
- HDMI 2.0
- USB 1.1
Extends an HDMI signal to a distance of up to 70 m in UHD resolution (4K/60Hz) and offers KVM/USB functionality for connecting a mouse, keyboard and touchscreen.
- Supports 4K2K/60Hz (HDR, 4:4:4)
- Video bandwidth: 18 Gbps
- Maximum transmission distance (UHD 4K2K): 70 m
- KVM/USB functionality - Connection of mouse, keyboard, touchscreen
- HDMI loop-out on the transmitter unit
- Supports CAT 6/7/8 cables
- Audio extractor on the receiver unit (S/PDIF)
- EDID Pass Back
- HDCP 2.2 / 1.4
- HDMI 2.0
- USB 1.1
Extends an HDMI signal to a distance of up to 70 m in UHD resolution (4K/60Hz) and offers KVM/USB functionality for connecting a mouse, keyboard and touchscreen.
Features
Type: Transmitter and receiver
Maximum possible transmission distance: 70 m
Supported cable types: Cat6, Cat7, Cat8
Product color: Black
Material: Aluminum
LED indicators: Status
Sender
Transmitter video connection type: HDMI
Number of displays supported: 2
Number of RJ-45 ports (transmitter): 1
Recipient
Receiver local video connection type: HDMI
Receiver local keyboard/mouse connection type: USB
Number of RJ-45 ports (receiver): 1
Connections and interfaces
USB port type: Mini-USB A
HDMI version: 2.0
Number of RJ-45 ports: 2
energy
Power supply output voltage: 5 V
AC adapter output current: 2 A
Power consumption (transmitter) (max.): 4 W
Power consumption (receiver) (max.): 4 W
Weight and dimensions
Transmitter width: 15 cm
Transmitter depth: 10.7 cm
Transmitter height: 2.8 cm
Transmitter weight: 260 g
Receiver width: 15 cm
Receiver depth: 10.7 cm
Receiver height: 2.8 cm
Receiver weight: 260 g
Packaging data
Packaging width: 153 mm
Packaging depth: 357 mm
Packaging height: 85 mm
Package weight: 1.1 kg
Scope of delivery
AC power adapter: Yes
Included cable: USB
Operating instructions: Yes
Mounting brackets included: Yes
Operating conditions
Operating temperature: -20 - 60 °C
Technical details
Maximum resolution: 3840 x 2160 pixels
Packaging volume: 4642.79 cm³
Logistics data
Country of origin: China
Type: Transmitter and receiver
Maximum possible transmission distance: 70 m
Supported cable types: Cat6, Cat7, Cat8
Product color: Black
Material: Aluminum
LED indicators: Status
Sender
Transmitter video connection type: HDMI
Number of displays supported: 2
Number of RJ-45 ports (transmitter): 1
Recipient
Receiver local video connection type: HDMI
Receiver local keyboard/mouse connection type: USB
Number of RJ-45 ports (receiver): 1
Connections and interfaces
USB port type: Mini-USB A
HDMI version: 2.0
Number of RJ-45 ports: 2
energy
Power supply output voltage: 5 V
AC adapter output current: 2 A
Power consumption (transmitter) (max.): 4 W
Power consumption (receiver) (max.): 4 W
Weight and dimensions
Transmitter width: 15 cm
Transmitter depth: 10.7 cm
Transmitter height: 2.8 cm
Transmitter weight: 260 g
Receiver width: 15 cm
Receiver depth: 10.7 cm
Receiver height: 2.8 cm
Receiver weight: 260 g
Packaging data
Packaging width: 153 mm
Packaging depth: 357 mm
Packaging height: 85 mm
Package weight: 1.1 kg
Scope of delivery
AC power adapter: Yes
Included cable: USB
Operating instructions: Yes
Mounting brackets included: Yes
Operating conditions
Operating temperature: -20 - 60 °C
Technical details
Maximum resolution: 3840 x 2160 pixels
Packaging volume: 4642.79 cm³
Logistics data
Country of origin: China
