Datalogic QuickScan Mobile QM2131, Portable Barcode Reader, 1D, CCD, 400 reads/second, 0 - 120,000 lux, 0 - 45°. Datalogic QuickScan Mobile QM2131. Type: Portable barcode reader, Scanner type: 1D, Sensor type: CCD. Transmission technology: Wired & Wireless, Standard interfaces: USB, Radio frequency: 433 MHz. Product color: Black, International protection rating (IP code): IP42, LED indicators: Power. Power source: Rechargeable battery, DC, Battery technology: Lithium-ion (Li-ion), Battery capacity: 1400 mAh. Weight: 190 g, Width: 91 mm, Depth: 41 mm
Podijelite:
Traditional codes can be found, for example, on utility bills, in document processing, and also in the packaging industry. These long codes pose a real challenge for true area imagers due to their shorter field of view and shallower depth of field.
The extra-wide field of view of the QuickScan QM2131 imager and its exceptionally long scan line simplify the capture of long barcodes from close range. Thanks to the sharp and clearly defined scan line, reading is quick and easy for the user. Furthermore, the improved depth of field allows codes to be captured from an intuitive distance. The modern design is a hallmark of the QuickScan series and distinguishes the entire family.
Using Datalogic“s STAR 2.0 Cordless System for narrowband communication in the 433 MHz band, the QM2131 linear imager offers secure wireless communication without interfering with existing Wi-Fi infrastructures or being affected by obstacles such as concrete walls or metal shelves.
The extra-wide field of view of the QuickScan QM2131 imager and its exceptionally long scan line simplify the capture of long barcodes from close range. Thanks to the sharp and clearly defined scan line, reading is quick and easy for the user. Furthermore, the improved depth of field allows codes to be captured from an intuitive distance. The modern design is a hallmark of the QuickScan series and distinguishes the entire family.
Using Datalogic“s STAR 2.0 Cordless System for narrowband communication in the 433 MHz band, the QM2131 linear imager offers secure wireless communication without interfering with existing Wi-Fi infrastructures or being affected by obstacles such as concrete walls or metal shelves.
Scan
Type: Portable barcode reader
Scanner type: 1D
Sensor type: CCD
Maximum read speed: 400 reads/second
Light levels (direct sunlight): 0 - 120000 lux
Tilt reading angle: 0 - 45°
Slope reading angle: 0 - 65°
Yaw reading angle: 0 - 70°
Connections and interfaces
Transmission technology: Wired & Wireless
Standard interfaces: USB
Radio frequency: 433 MHz
Cable length: 1.5 m
Services
International protection rating (IP code): IP42
LED indicators: Performance
Product color: Black
Certification: China RoHS, EU RoHS
energy
Energy source: Battery, direct current
Battery technology: Lithium-ion (Li-ion)
Battery/Battery Capacity: 1400mAh
Number of reads per load: 30000
Charging time: 4 hours
Weight and dimensions
Width: 91 mm
Depth: 41 mm
Height: 163 mm
Weight: 190 g
Base weight: 215 g
Packaging data
Included cable: USB
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: 40 - 70 °C
Relative humidity during operation: 0 - 50%
Logistics data
Commodity tariff number (HS): 84716070
Type: Portable barcode reader
Scanner type: 1D
Sensor type: CCD
Maximum read speed: 400 reads/second
Light levels (direct sunlight): 0 - 120000 lux
Tilt reading angle: 0 - 45°
Slope reading angle: 0 - 65°
Yaw reading angle: 0 - 70°
Connections and interfaces
Transmission technology: Wired & Wireless
Standard interfaces: USB
Radio frequency: 433 MHz
Cable length: 1.5 m
Services
International protection rating (IP code): IP42
LED indicators: Performance
Product color: Black
Certification: China RoHS, EU RoHS
energy
Energy source: Battery, direct current
Battery technology: Lithium-ion (Li-ion)
Battery/Battery Capacity: 1400mAh
Number of reads per load: 30000
Charging time: 4 hours
Weight and dimensions
Width: 91 mm
Depth: 41 mm
Height: 163 mm
Weight: 190 g
Base weight: 215 g
Packaging data
Included cable: USB
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: 40 - 70 °C
Relative humidity during operation: 0 - 50%
Logistics data
Commodity tariff number (HS): 84716070
