QuickScan Mobile QM2131, 433 MHz, kit, USB, linear imager, black (kit incl. imager and base station and USB cable 90A052258)
Datalogic QuickScan Mobile QM2131, portable barcode reader, 1D, CCD, 400 readings/second, 0 - 120000 lux, 0 - 45°
Datalogic QuickScan Mobile QM2131. Type: Portable barcode reader, Scanner type: 1D, Sensor type: CCD. Transmission technology: Wired & Wireless, Standard interfaces: USB, Radio frequency: 433 MHz. Product color: Black, International Protection (IP) code: IP42, LED indicators: Power. Power source: Rechargeable battery, DC, Rechargeable battery/battery technology: Lithium-ion (Li-ion), Rechargeable battery/battery capacity: 1400 mAh. Weight: 190g, Width: 91mm, Depth: 41mm
Podijelite:Datalogic QuickScan Mobile QM2131, portable barcode reader, 1D, CCD, 400 readings/second, 0 - 120000 lux, 0 - 45°
Datalogic QuickScan Mobile QM2131. Type: Portable barcode reader, Scanner type: 1D, Sensor type: CCD. Transmission technology: Wired & Wireless, Standard interfaces: USB, Radio frequency: 433 MHz. Product color: Black, International Protection (IP) code: IP42, LED indicators: Power. Power source: Rechargeable battery, DC, Rechargeable battery/battery technology: Lithium-ion (Li-ion), Rechargeable battery/battery capacity: 1400 mAh. Weight: 190g, Width: 91mm, Depth: 41mm
Traditional codes can be found, for example, on utility bills, in document processing and also in the packaging sector. These long codes are a real challenge for real area imagers due to their shorter field of view and shallower depth of field.
The extra wide field of view of the QuickScan QM2131 imager and its particularly long scanning line simplify the capture of long barcodes from a short distance. Reading is quick and easy for the user thanks to the sharp and clearly visible scan line. In addition, the improved depth of field ensures that codes can be captured from an intuitive distance. The modern design is the hallmark of the QuickScan series and distinguishes the entire family.
With Datalogic“s STAR 2.0 Cordless System for narrowband communication in the 433 MHz band, the QM2131 linear imager offers secure radio communication without disrupting existing Wi-Fi infrastructure or being affected by obstacles such as concrete walls or metal shelves.
The extra wide field of view of the QuickScan QM2131 imager and its particularly long scanning line simplify the capture of long barcodes from a short distance. Reading is quick and easy for the user thanks to the sharp and clearly visible scan line. In addition, the improved depth of field ensures that codes can be captured from an intuitive distance. The modern design is the hallmark of the QuickScan series and distinguishes the entire family.
With Datalogic“s STAR 2.0 Cordless System for narrowband communication in the 433 MHz band, the QM2131 linear imager offers secure radio communication without disrupting existing Wi-Fi infrastructure or being affected by obstacles such as concrete walls or metal shelves.
to scan
Type: Portable Barcode Reader
Scanner Type: 1D
Sensor Type: CCD
Reading speed (max): 400 readings/second
Light levels (direct sunlight): 0 - 120,000 lux
Tilt reading angle: 0 - 45°
Gradient reading angle: 0 - 65°
Yaw reading angle: 0 - 70°
Connections and interfaces
Transmission technology: Wired & Wireless
Standard interfaces: USB
Radio frequency: 433 MHz
Cable length: 1.5 m
Services
Product color: Black
International protection class (IP code): IP42
LED indicators: performance
Certification: China RoHS, EU RoHS
Performance
Power source: battery, direct current
Rechargeable battery/battery technology: Lithium-Ion (Li-Ion)
Battery/Battery Capacity: 1400mAh
Number of reads per charge: 30000
Charging time: 4 hours
Weight and dimensions
Weight: 190g
Width: 91mm
Depth: 41mm
Height: 163mm
Base weight: 215g
Packaging data
Cables included: USB
Operating conditions
Operating temperature: 0 - 40°C
Storage temperature range: 40 - 70 °C
Relative humidity in operation: 0 - 50%
Logistics data
Goods tariff number (HS): 84716070
Type: Portable Barcode Reader
Scanner Type: 1D
Sensor Type: CCD
Reading speed (max): 400 readings/second
Light levels (direct sunlight): 0 - 120,000 lux
Tilt reading angle: 0 - 45°
Gradient reading angle: 0 - 65°
Yaw reading angle: 0 - 70°
Connections and interfaces
Transmission technology: Wired & Wireless
Standard interfaces: USB
Radio frequency: 433 MHz
Cable length: 1.5 m
Services
Product color: Black
International protection class (IP code): IP42
LED indicators: performance
Certification: China RoHS, EU RoHS
Performance
Power source: battery, direct current
Rechargeable battery/battery technology: Lithium-Ion (Li-Ion)
Battery/Battery Capacity: 1400mAh
Number of reads per charge: 30000
Charging time: 4 hours
Weight and dimensions
Weight: 190g
Width: 91mm
Depth: 41mm
Height: 163mm
Base weight: 215g
Packaging data
Cables included: USB
Operating conditions
Operating temperature: 0 - 40°C
Storage temperature range: 40 - 70 °C
Relative humidity in operation: 0 - 50%
Logistics data
Goods tariff number (HS): 84716070
