be quiet! Straight Power 12, 750 W, 110-240 V, 820 W, 50/60 Hz, 10/5 A, 130 W be quiet! Straight Power 12. Total power: 750 W, AC input voltage: 110-240 V, Peak current: 820 W. Motherboard connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 550, 700, 850, 1000 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 Plus certification: 80 PLUS Platinum. Product color: Black, Cooling: Active, Fan diameter: 13.5 cm. Included cables: CPU, SATA
Podijelite:
energy
Total power: 750 W
Peak current: 820 W
AC input voltage: 110 - 240 V
AC input frequency: 50/60 Hz
Input current: 10/5 A
Power factor: 0.99
Combined current (+3.3V): 130 W
Combined power (+12V): 750 W
Combined current (+5V): 130 W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 62.5 A
Max output current (+5V): 25 A
Max. output current (-12V): 0.3 A
Max. output current (+5Vsb): 3 A
Hold time: 24.8 ms
Efficiency: 92.9%
Energy protection features: overcurrent, overload, overvoltage, overheating, short circuit, undervoltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 60 cm
Number of SATA power connectors: 9
Number of PATA power connections: 2
SATA power cable length: 550, 700, 850, 1000 mm
Peripheral (Molex) power cable length: 1000.850 mm
Feature: EPS power connector (8-pin)
Feature: EPS power connector (4+4 pin)
Number of PCI Express power connectors 6+2pin: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 60 cm
CPU performance Cable length: 70 cm
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Platinum
Supported motherboard form factors: ATX, micro ATX, Mini-ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
EPS version: 2.92
Noise level: 20.8 dB
Bearing type: FDB
Mean time between failures (MTBF): 100,000 h
design
Product color: Black
Cooling: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan
Fan speed: 0 - 1800 RPM
Feature: On/Off switch
Operating conditions
Operating temperature: 0 - 40 °C
Scope of delivery
Included cables: CPU, SATA
Feature: Cable ties included
Certificates
Conformity certificates: CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE
Weight and dimensions
Width: 150 mm
Depth: 160 mm
Height: 86 mm
Weight: 1.76 kg
Packaging data
Packaging width: 248 mm
Packaging depth: 328 mm
Packaging height: 102 mm
Package weight: 3.47 kg
Packaging type: Box
Technical details
Feature: Sustainability compliance
Logistics data
Shipping carton length: 65.1 cm
Shipping box width: 28.2 cm
Shipping box height: 34.6 cm
Net weight of shipping carton: 22.4 kg
Quantity per shipping carton: 6 pieces
Warranty period: 10 year(s)
Total power: 750 W
Peak current: 820 W
AC input voltage: 110 - 240 V
AC input frequency: 50/60 Hz
Input current: 10/5 A
Power factor: 0.99
Combined current (+3.3V): 130 W
Combined power (+12V): 750 W
Combined current (+5V): 130 W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 62.5 A
Max output current (+5V): 25 A
Max. output current (-12V): 0.3 A
Max. output current (+5Vsb): 3 A
Hold time: 24.8 ms
Efficiency: 92.9%
Energy protection features: overcurrent, overload, overvoltage, overheating, short circuit, undervoltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 60 cm
Number of SATA power connectors: 9
Number of PATA power connections: 2
SATA power cable length: 550, 700, 850, 1000 mm
Peripheral (Molex) power cable length: 1000.850 mm
Feature: EPS power connector (8-pin)
Feature: EPS power connector (4+4 pin)
Number of PCI Express power connectors 6+2pin: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 60 cm
CPU performance Cable length: 70 cm
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Platinum
Supported motherboard form factors: ATX, micro ATX, Mini-ATX
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
EPS version: 2.92
Noise level: 20.8 dB
Bearing type: FDB
Mean time between failures (MTBF): 100,000 h
design
Product color: Black
Cooling: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan
Fan speed: 0 - 1800 RPM
Feature: On/Off switch
Operating conditions
Operating temperature: 0 - 40 °C
Scope of delivery
Included cables: CPU, SATA
Feature: Cable ties included
Certificates
Conformity certificates: CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE
Weight and dimensions
Width: 150 mm
Depth: 160 mm
Height: 86 mm
Weight: 1.76 kg
Packaging data
Packaging width: 248 mm
Packaging depth: 328 mm
Packaging height: 102 mm
Package weight: 3.47 kg
Packaging type: Box
Technical details
Feature: Sustainability compliance
Logistics data
Shipping carton length: 65.1 cm
Shipping box width: 28.2 cm
Shipping box height: 34.6 cm
Net weight of shipping carton: 22.4 kg
Quantity per shipping carton: 6 pieces
Warranty period: 10 year(s)
