The Ubiquiti UniFi Flex 2.5G is designed to enhance networking capabilities with its performance features. It supports up to 4,000 MAC addresses and 256 VLANs, ensuring efficient network management for various environments. With a switching capacity of 60 Gbps, this switch effectively handles significant data loads. The device features 10 total ports, including 8 ports capable of 2.5GBase-T and two 10Gb Ethernet ports, providing versatile connectivity options. Designed for various mounting options, this switch operates within a temperature range of -20°C to 45°C and maintains efficient performance in humidity levels from 10% to 90% (non-condensing).
Management functions
Switch type: Managed
Switch level: L2
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: 2.5G Ethernet (100/1000/2500)
Number of 2.5G Ethernet (copper) ports: 8
Number of 10G Ethernet (copper) ports: 1
Number of SFP+ module slots: 1
network
10G support: Yes
Port mirroring: Yes
Data flow control support: Yes
Broadcast storm control: Yes
Rate limit: Yes
Ethernet LAN data transfer rates: 10, 100, 1000, 2500 Mbit/s
VLAN support: Yes
Number of VLANs: 256
Data transmission
Routing/switching capacity: 60 Gbit/s
Throughput: 30 Gbit/s
Transfer rate: 45 MPPS
MAC address table: 4000 entries
Jumbo Frames Support: Yes
Security
Loop Protection: Yes
Multicast functions
Multicast support: Yes
design
Form factor: Desktop/wall mount
Product color: White
Housing material: Polycarbonate (PC)
LED indicators: Activity, Link, Performance, Status
Wall mounting: Yes
DIN rail mounting: Yes
energy
Power source: PoE/USB
Power supply included: No
Input current: 3.9 A
Power consumption (max.): 17 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Operating conditions
Operating temperature: -20 - 45 °C
Relative humidity during operation: 10 - 90%
Weight and dimensions
Width: 212.9 mm
Depth: 99.4 mm
Height: 33.5 mm
Weight: 567 g
Certificates
Certificates of conformity: CE, Federal Communications Commission (FCC), Industry Canada (IC)
Switch type: Managed
Switch level: L2
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: 2.5G Ethernet (100/1000/2500)
Number of 2.5G Ethernet (copper) ports: 8
Number of 10G Ethernet (copper) ports: 1
Number of SFP+ module slots: 1
network
10G support: Yes
Port mirroring: Yes
Data flow control support: Yes
Broadcast storm control: Yes
Rate limit: Yes
Ethernet LAN data transfer rates: 10, 100, 1000, 2500 Mbit/s
VLAN support: Yes
Number of VLANs: 256
Data transmission
Routing/switching capacity: 60 Gbit/s
Throughput: 30 Gbit/s
Transfer rate: 45 MPPS
MAC address table: 4000 entries
Jumbo Frames Support: Yes
Security
Loop Protection: Yes
Multicast functions
Multicast support: Yes
design
Form factor: Desktop/wall mount
Product color: White
Housing material: Polycarbonate (PC)
LED indicators: Activity, Link, Performance, Status
Wall mounting: Yes
DIN rail mounting: Yes
energy
Power source: PoE/USB
Power supply included: No
Input current: 3.9 A
Power consumption (max.): 17 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Operating conditions
Operating temperature: -20 - 45 °C
Relative humidity during operation: 10 - 90%
Weight and dimensions
Width: 212.9 mm
Depth: 99.4 mm
Height: 33.5 mm
Weight: 567 g
Certificates
Certificates of conformity: CE, Federal Communications Commission (FCC), Industry Canada (IC)
