Management functions
Switch type: Managed
Switch level: L2/L3
Feature: Quality of Service (QoS) Support
Connections and interfaces
Number of SFP+ module slots: 16
Console Port: RJ-45/USB Type-C
network
Network standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
Feature: 10G support
Feature: Full duplex
Property: Link Aggregation
Feature: Broadcast Storm Control
Property: Rate Limiting
Property: Spanning Tree Protocol
Feature: VLAN support
Virtual LAN functions: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs: 4093
Data transfer
Routing/switching capacity: 320 Gbit/s
Pass: 238.08 Mpps
MAC address table: 16000 entries
Property: Store-and-Forward
Latency (1 Gbps): 1.274 µs
Latency (10 Gbps): 0.811 µs
Number of queues: 8
Feature: Jumbo Frames Support
Jumbo frames: 12000
Data packet buffer memory: 16 MB
Security
DHCP functions: DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Property: Access Control List
Property: IGMP snooping
Feature: SSH/SSL support
Feature: Loop Protection
Feature: BPDU filtering/protection
Authentication: MAC-based authentication
Authentication type: RADIUS
Multicast functions
Feature: Multicast support
IPv4 multicast entries: 2000
IPv6 multicast entries: 2000
design
Feature: Rack mounting
Form factor: 1U
Product color: Black
LED indicators: PoE, power, status
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock frequency: 1250 MHz
Storage capacity: 2048 MB
Noise level: 56.7 dB
Mean time between failures (MTBF): 778,769 h
energy
Power consumption (standard operation): 47.84 W
Operating conditions
Operating temperature: 0 - 50 °C
Storage temperature range: -20 - 70 °C
Relative humidity during operation: 0 - 90%
Storage humidity: 0 - 95%
Operating altitude: 0 - 3000 m
Heat dissipation: 163.33 BTU/h
Weight and dimensions
Width: 440 mm
Depth: 100 mm
Height: 43.2 mm
Weight: 1.74 kg
Logistics data
Tariff number (HS): 85176990
Switch type: Managed
Switch level: L2/L3
Feature: Quality of Service (QoS) Support
Connections and interfaces
Number of SFP+ module slots: 16
Console Port: RJ-45/USB Type-C
network
Network standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
Feature: 10G support
Feature: Full duplex
Property: Link Aggregation
Feature: Broadcast Storm Control
Property: Rate Limiting
Property: Spanning Tree Protocol
Feature: VLAN support
Virtual LAN functions: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs: 4093
Data transfer
Routing/switching capacity: 320 Gbit/s
Pass: 238.08 Mpps
MAC address table: 16000 entries
Property: Store-and-Forward
Latency (1 Gbps): 1.274 µs
Latency (10 Gbps): 0.811 µs
Number of queues: 8
Feature: Jumbo Frames Support
Jumbo frames: 12000
Data packet buffer memory: 16 MB
Security
DHCP functions: DHCP Option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Property: Access Control List
Property: IGMP snooping
Feature: SSH/SSL support
Feature: Loop Protection
Feature: BPDU filtering/protection
Authentication: MAC-based authentication
Authentication type: RADIUS
Multicast functions
Feature: Multicast support
IPv4 multicast entries: 2000
IPv6 multicast entries: 2000
design
Feature: Rack mounting
Form factor: 1U
Product color: Black
LED indicators: PoE, power, status
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock frequency: 1250 MHz
Storage capacity: 2048 MB
Noise level: 56.7 dB
Mean time between failures (MTBF): 778,769 h
energy
Power consumption (standard operation): 47.84 W
Operating conditions
Operating temperature: 0 - 50 °C
Storage temperature range: -20 - 70 °C
Relative humidity during operation: 0 - 90%
Storage humidity: 0 - 95%
Operating altitude: 0 - 3000 m
Heat dissipation: 163.33 BTU/h
Weight and dimensions
Width: 440 mm
Depth: 100 mm
Height: 43.2 mm
Weight: 1.74 kg
Logistics data
Tariff number (HS): 85176990
