Neomounts WL30S-950BL19 Heavy-Duty Wall Mount 55-115“ - Fixed - Lockable - Landscape and Portrait Orientation, 2.92 m (115“), 100 x 100 mm, 1500 x 900 mm, 6°, Steel, Black. Maximum weight capacity: 160 kg, Minimum screen size: 139.7 cm (55“), Maximum screen size: 2.92 m (115“), Minimum VESA mount: 100 x 100 mm, Maximum VESA mount: 1500 x 900 mm. Height adjustment: 0-20 mm, Rotation angle: 6°, Distance to wall (max): 6.7 cm. Product color: Black
Podijelite:
The Neomounts WL30S-950BL19 is a sturdy, heavy-duty wall mount for flat screens up to 115“ with a maximum load capacity of 160 kg. It allows for portrait and landscape orientation. The mount features individually height-adjustable brackets and a leveling mechanism for perfect installation.
The WL30S-950BL19 has a depth of 6.5 cm and, thanks to the included vertical extension brackets, is suitable for screens with VESA hole patterns from 100x100 to 1500x900 mm. Its unique extendable design allows the mount to be adjusted to a wide range of screen sizes, from 55“ to 115“. The mount can be secured with a padlock (not included).
The mount features a clever magnetic pull-and-release system, allowing you to install your TV securely and stably in no time. The pull-and-release straps can then be easily concealed behind the screen by simply clicking the magnet onto the mount. A separate spirit level is included with the wall mount to ensure easy installation.
The WL30S-950BL19 has a depth of 6.5 cm and, thanks to the included vertical extension brackets, is suitable for screens with VESA hole patterns from 100x100 to 1500x900 mm. Its unique extendable design allows the mount to be adjusted to a wide range of screen sizes, from 55“ to 115“. The mount can be secured with a padlock (not included).
The mount features a clever magnetic pull-and-release system, allowing you to install your TV securely and stably in no time. The pull-and-release straps can then be easily concealed behind the screen by simply clicking the magnet onto the mount. A separate spirit level is included with the wall mount to ensure easy installation.
Assembly
Maximum weight capacity: 160 kg
Minimum screen size: 139.7 cm (55“)
Number of supported displays: 1
Maximum weight capacity (per monitor): 160 kg
Maximum screen size: 2.92 m (115“)
Minimum VESA mount: 100 x 100 mm
Maximum VESA mount: 1500 x 900 mm
Panel mounting interface: 1000 x 400,1000 x 600,1000 x 800,1000 x 700,100 x 200,100 x 100,100 x 150,1200 x 600,1200 x 800,1200 x 900,1400 x 800,1500 x 900,1500 x 600,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 900,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,440 x 400,460 x 640,500 x 500,500 x 400,600 x 300,600 x 200,600 x 400,600 x 500,600 x 600,680 x 300,800 x 800,800 x 200,800 x 400,800 x 500,800 x 600,900 x 600
Mounting type: Wall
ergonomics
Height adjustment: Yes
Height adjustment rate: 0 - 20 mm
Rotation angle: 6°
Pivot angle: -3 - 3°
Distance to wall (max): 6.7 cm
design
Product color: Black
Housing material: Steel
Accepts padlocks: Yes
Technical details
Country of origin: China
Net weight of packaging: 11.7 kg
Orientation: Landscape portrait
Warranty period: 5 years
Lockable: Security screw included
Weight and dimensions
Width: 1600 mm
Depth: 67 mm
Depth (max): 6.7 cm
Height: 936 mm
Weight: 10.2 kg
Packaging data
Packaging width: 222 mm
Packaging depth: 98 mm
Packaging height: 918 mm
Package weight: 11.7 kg
Logistics data
Shipping carton width: 211 mm
Length of shipping carton: 242 mm
Shipping carton height: 938 mm
Shipping carton weight: 23.9 kg
Net weight of main carton: 20.3 kg
Number of products per shipping carton: 2 pieces
Commodity tariff number (HS): 7326909890
Quantity per Euro pallet: 30 pieces
Other functions
Wide adjustment range: 893 - 1600 mm
Maximum weight capacity: 160 kg
Minimum screen size: 139.7 cm (55“)
Number of supported displays: 1
Maximum weight capacity (per monitor): 160 kg
Maximum screen size: 2.92 m (115“)
Minimum VESA mount: 100 x 100 mm
Maximum VESA mount: 1500 x 900 mm
Panel mounting interface: 1000 x 400,1000 x 600,1000 x 800,1000 x 700,100 x 200,100 x 100,100 x 150,1200 x 600,1200 x 800,1200 x 900,1400 x 800,1500 x 900,1500 x 600,200 x 100,200 x 150,200 x 200,200 x 300,200 x 400,300 x 900,300 x 100,300 x 200,300 x 300,350 x 350,400 x 200,400 x 300,400 x 400,400 x 600,440 x 400,460 x 640,500 x 500,500 x 400,600 x 300,600 x 200,600 x 400,600 x 500,600 x 600,680 x 300,800 x 800,800 x 200,800 x 400,800 x 500,800 x 600,900 x 600
Mounting type: Wall
ergonomics
Height adjustment: Yes
Height adjustment rate: 0 - 20 mm
Rotation angle: 6°
Pivot angle: -3 - 3°
Distance to wall (max): 6.7 cm
design
Product color: Black
Housing material: Steel
Accepts padlocks: Yes
Technical details
Country of origin: China
Net weight of packaging: 11.7 kg
Orientation: Landscape portrait
Warranty period: 5 years
Lockable: Security screw included
Weight and dimensions
Width: 1600 mm
Depth: 67 mm
Depth (max): 6.7 cm
Height: 936 mm
Weight: 10.2 kg
Packaging data
Packaging width: 222 mm
Packaging depth: 98 mm
Packaging height: 918 mm
Package weight: 11.7 kg
Logistics data
Shipping carton width: 211 mm
Length of shipping carton: 242 mm
Shipping carton height: 938 mm
Shipping carton weight: 23.9 kg
Net weight of main carton: 20.3 kg
Number of products per shipping carton: 2 pieces
Commodity tariff number (HS): 7326909890
Quantity per Euro pallet: 30 pieces
Other functions
Wide adjustment range: 893 - 1600 mm
