MSI Cubi NUC 1MG-023DE i3-100U/black/8GB/256GB SSD W11P

processor
Processor manufacturer: Intel
Processor family: Intel Core 3
Processor generation: Intel Core (Series 1)
Processor: 100U
Number of processor cores: 6
Processor threads: 8
Processor boost frequency: 4.7 GHz
Performance cores: 2
Efficient cores: 4
Performance core maximum turbo frequency: 4.7 GHz
Efficient core maximum turbo frequency: 3.3 GHz
Performance Base frequency of the core: 1.2 GHz
Efficient base frequency of the core: 0.9 GHz
Processor cache: 10 MB
Processor Cache Type: Smart Cache
Number of supported processors: 1
Base power consumption of the processor: 15 W
Maximum turbo power: 55 W
memory
Storage capacity: 8 GB
Maximum RAM: 64 GB
Internal memory type: DDR5-SDRAM
Memory card slots: 2x SO-DIMM
Memory clock speed: 5600 MHz
Supported memory types: DDR5-SDRAM
Storage medium
Total storage capacity: 256 GB
Storage media: SSD
Optical drive - Type: No
Total SSD capacity: 256 GB
Number of SSDs installed: 1
SSD storage capacity: 256 GB
SSD interface: PCI Express 4.0
NVMe: Yes
SSD form factor: M.2
Integrated card reader: Yes
Compatible memory cards: MicroSD (TransFlash)
graphic
Separate graphics adapter: No
Built-in graphics adapter: Yes
Separate graphics card model: Not available
Manufacturer of the integrated GPU: Intel
On-board graphics adapter family: Intel Graphics
Built-in graphics card model: Intel Graphics
network
Ethernet/LAN: Yes
LAN controller: Intel I226-V
Wi-Fi: Yes
Top WLAN standard: Wi-Fi 6E (802.11ax)
WLAN standards: Wi-Fi 6E (802.11ax)
WiFi controller model: Intel Wi-Fi 6E AX211
Bluetooth: Yes
Bluetooth version: 5.3
Connections and interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 4
Intel® Thunderbolt 4: Yes
Number of Thunderbolt 4 ports: 2
DVI connection: No
Number of HDMI ports: 2
HDMI version: 1.4b/2.1
Number of Ethernet LAN ports (RJ-45): 2
Microphone input: No
Headphone outputs: 1
Combined headphone/microphone jack: Yes
Direct current (DC) connection: Yes
design
Case type: Mini PC
VESA mount: Yes
Cable lock slot: Yes
Cable lock slot type: Kensington
Product color: Black
Housing material: Plastic
Services
Motherboard chipset: Intel SoC
Motherboard form factor: NUC
Built-in speakers: No
Trusted Platform Module (TPM): Yes
Product type: Mini PC
Trusted Platform Module (TPM) Version: 2.0
software
Installed operating system: Windows 11 Pro
energy
Power supply: 120 W
Operating conditions
Operating temperature: 0 - 35 °C
Storage temperature range: -20 - 60 °C
Relative humidity during operation: 0 - 85%
Storage humidity: 0 - 90%
Certificates
Certifications: FCC (Class B), CB/CE, UL (CUL), BSMI, VCCI, RCM (C-Tick)
Weight and dimensions
Width: 132.5 mm
Depth: 135.6 mm
Height: 50.1 mm
Weight: 630 g
Packaging width: 205 mm
Packaging depth: 220 mm
Packaging height: 94 mm
Package weight: 1.38 kg
Scope of delivery
Mouse included: No
Keyboard included: No
AC power adapter: Yes
Power cable included: Yes
Screen
Advertisement included: No
Other functions
Power supply type: External AC adapter
Panel mounting interface: 100 x 100 mm
Graphics card family: Intel
Cooling: Active
Number of displays supported: 4
Number of M.2 (M) slots: 2
