MSI Cubi NUC 1MG-019DE i7-150Ublack/16GB/512GB SSD W11P

processor
Processor manufacturer: Intel
Processor family: Intel Core 7
Processor generation: Intel Core (Series 1)
Processor: 150U
Number of processor cores: 10
Processor threads: 12
Performance cores: 2
Efficient cores: 8
Performance core maximum turbo frequency: 5.4 GHz
Efficient core maximum turbo frequency: 4 GHz
Performance Base frequency of the core: 1.8 GHz
Efficient base frequency of the core: 1.2 GHz
Processor cache: 12 MB
Number of installed processors: 1
Base power consumption of the processor: 15 W
Maximum turbo power: 55 W
memory
Storage capacity: 16 GB
Maximum RAM: 64 GB
Internal memory type: DDR5-SDRAM
Memory layout: 2 x 8 GB
Memory card slots: 2x SO-DIMM
Memory clock speed: 5200 MHz
Storage medium
Total storage capacity: 512 GB
Storage media: SSD
Optical drive - Type: No
Number of installed storage drives: 1
Number of supported storage drives: 3
HDD size: 2.5“
Total SSD capacity: 512 GB
Number of SSDs installed: 1
SSD storage capacity: 512 GB
SSD interface: M.2
NVMe: Yes
SSD form factor: M.2
M.2 SSD size: 2280 (22 x 80 mm)
Integrated card reader: Yes
Compatible memory cards: MicroSD (TransFlash)
graphic
Separate graphics adapter: No
Built-in graphics adapter: Yes
Separate graphics card model: Not available
Manufacturer of the integrated GPU: Intel
On-board graphics adapter family: Intel Iris Xe Graphics
Built-in graphics card model: Intel Iris Xe Graphics
network
Ethernet/LAN: Yes
LAN controller: Intel I226-V
Wi-Fi: Yes
Top WLAN standard: Wi-Fi 6E (802.11ax)
WLAN standards: Wi-Fi 6E (802.11ax)
Manufacturer of WLAN controllers: Intel
WiFi controller model: Intel Wi-Fi 6E AX211
Bluetooth: Yes
Bluetooth version: 5.3
Wake-on-LAN ready: Yes
Connections and interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 4
PowerShare: No
USB Type-C DisplayPort switching mode: Yes
Intel® Thunderbolt 4: Yes
Number of Thunderbolt 4 ports: 2
DVI connection: No
Number of HDMI ports: 2
HDMI version: 1.4/2.1
Number of Ethernet LAN ports (RJ-45): 2
Microphone input: No
Headphone outputs: 1
Line-out: No
Line-in: No
Combined headphone/microphone jack: Yes
S/PDIF output: No
Direct current (DC) connection: Yes
Number of rear USB ports: 4
Number of front USB ports: 2
Number of front audio connections: 1
Fiber optic NIC connection (Flex I/O): No
design
Case type: Mini PC
Color name: Black
Volume (l): 0.84 l
Supported positioning: Horizontal
VESA mount: Yes
Cable lock slot: Yes
Cable lock slot type: Kensington
Product color: Black
Housing material: Plastic
Viewing window: No
RGB storage lighting: No
Year of introduction: 2024
Month of introduction: July
Country of origin: China
Services
Market positioning: Business
Powered by: MSI
Motherboard chipset: Intel SoC
Motherboard form factor: NUC
Trusted Platform Module (TPM): Yes
Product type: Mini PC
Trusted Platform Module (TPM) Version: 2.0
software
Installed operating system: Windows 11 Pro
energy
Power supply: 120 W
Power supply - Input voltage: 100-240 V
Power supply - Input frequency: 50-60 Hz
Weight and dimensions
Width: 132.5 mm
Depth: 135.6 mm
Height: 50.1 mm
Weight: 630 g
Packaging data
Packaging width: 205 mm
Packaging depth: 220 mm
Packaging height: 94 mm
Package weight: 1.38 kg
Scope of delivery
Mouse included: No
Keyboard included: No
Included cables: AC, power
VESA mount included: Yes
Screws included: Yes
Screen
Advertisement included: No
Other functions
TV tuner integrated: No
Built-in microphone: No
Language environment: English
Warranty period: 3 year(s)
