MSI Cubi 5 12M-022BDE, 0.66L sized PC, Mini-PC Barebone, Ethernet/LAN, Wi-Fi 6E (802.11ax), 65 W. MSI Cubi 5 12M-022BDE. Case type: 0.66L sized PC, Product type: Mini-PC Barebone. Number of memory slots: 2, Maximum RAM: 64 GB. Supported storage drives: HDD & SSD. Number of Ethernet LAN ports (RJ-45): 2. WLAN standards: Wi-Fi 6E (802.11ax), Bluetooth version: 5.3. Power supply: 65 W.
Podijelite:
processor
Processor manufacturer: Intel
Processor family: Intel® Core™ i3
Processor generation: 12th generation Intel® Core™ i3 processors
Processor: i3-1215U
Number of processor cores: 6
Processor threads: 8
Processor boost frequency: 4.4 GHz
Performance cores: 2
Efficient cores: 4
Built-in processor: Yes
Processor lithography: 14 nm
Processor cache: 10 MB
Thermal Design Power (TDP): 15W
Processor Codename: Comet Lake
memory
Memory type: SO-DIMM
Number of memory slots: 2
Maximum RAM: 64 GB
Storage medium
Supported storage drives: HDD & SSD
Supported storage drive sizes: 2.5“, M.2
Number of supported storage drives: 2
graphic
Built-in graphics adapter: Yes
Graphics card family: Intel
Built-in graphics card model: Intel® UHD Graphics
Separate graphics card model: Not available
Audio
Built-in speakers: No
network
Top WLAN standard: Wi-Fi 6E (802.11ax)
WLAN standards: Wi-Fi 6E (802.11ax)
WiFi controller model: Intel Wi-Fi 6E AX211
Ethernet/LAN: Yes
Wi-Fi: Yes
Bluetooth: Yes
Bluetooth version: 5.3
Connections and interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 4
Number of HDMI ports: 1
HDMI version: 2.0b
Number of DisplayPort connectors: 1
DisplayPort version: 1.4
Number of Ethernet LAN ports (RJ-45): 2
Number of Thunderbolt 4 ports: 1
Expansion slots
PCI Express Slots Version: 3.0
design
Case type: 0.66L sized PC
Product color: Black
Cable lock slot: Yes
Cable lock slot type: Kensington
VESA mount: Yes
Panel mounting interface: 100 x 100 mm
Product type: Mini-PC Barebone
Services
Optical drive - Type: No
Certificates
Certification: FCC (Class B) CB/CEUL (CUL) BSM IVC CIRCM (C-Tick)
software
Installed operating system: No
energy
Power supply type: External AC adapter
Power supply: 65 W
Operating conditions
Operating temperature: 0 - 35 °C
Storage temperature range: -20 - 60 °C
Relative humidity during operation: 0 - 85%
Storage humidity: 0 - 90%
Weight and dimensions
Width: 124 mm
Depth: 124 mm
Height: 53.7 mm
Weight: 590 g
Packaging width: 221 mm
Packaging depth: 506 mm
Packaging height: 469 mm
Package weight: 1.33 kg
Scope of delivery
Advertisement included: No
Mouse included: No
Keyboard included: No
Processor manufacturer: Intel
Processor family: Intel® Core™ i3
Processor generation: 12th generation Intel® Core™ i3 processors
Processor: i3-1215U
Number of processor cores: 6
Processor threads: 8
Processor boost frequency: 4.4 GHz
Performance cores: 2
Efficient cores: 4
Built-in processor: Yes
Processor lithography: 14 nm
Processor cache: 10 MB
Thermal Design Power (TDP): 15W
Processor Codename: Comet Lake
memory
Memory type: SO-DIMM
Number of memory slots: 2
Maximum RAM: 64 GB
Storage medium
Supported storage drives: HDD & SSD
Supported storage drive sizes: 2.5“, M.2
Number of supported storage drives: 2
graphic
Built-in graphics adapter: Yes
Graphics card family: Intel
Built-in graphics card model: Intel® UHD Graphics
Separate graphics card model: Not available
Audio
Built-in speakers: No
network
Top WLAN standard: Wi-Fi 6E (802.11ax)
WLAN standards: Wi-Fi 6E (802.11ax)
WiFi controller model: Intel Wi-Fi 6E AX211
Ethernet/LAN: Yes
Wi-Fi: Yes
Bluetooth: Yes
Bluetooth version: 5.3
Connections and interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 4
Number of HDMI ports: 1
HDMI version: 2.0b
Number of DisplayPort connectors: 1
DisplayPort version: 1.4
Number of Ethernet LAN ports (RJ-45): 2
Number of Thunderbolt 4 ports: 1
Expansion slots
PCI Express Slots Version: 3.0
design
Case type: 0.66L sized PC
Product color: Black
Cable lock slot: Yes
Cable lock slot type: Kensington
VESA mount: Yes
Panel mounting interface: 100 x 100 mm
Product type: Mini-PC Barebone
Services
Optical drive - Type: No
Certificates
Certification: FCC (Class B) CB/CEUL (CUL) BSM IVC CIRCM (C-Tick)
software
Installed operating system: No
energy
Power supply type: External AC adapter
Power supply: 65 W
Operating conditions
Operating temperature: 0 - 35 °C
Storage temperature range: -20 - 60 °C
Relative humidity during operation: 0 - 85%
Storage humidity: 0 - 90%
Weight and dimensions
Width: 124 mm
Depth: 124 mm
Height: 53.7 mm
Weight: 590 g
Packaging width: 221 mm
Packaging depth: 506 mm
Packaging height: 469 mm
Package weight: 1.33 kg
Scope of delivery
Advertisement included: No
Mouse included: No
Keyboard included: No
