Chipset: AMD B650 / Processor socket: Socket AM5 / Memory support: 4x DDR5 / Form factor: Micro-ATX
| series - motherboards | ||
| series | MSI PRO series | |
| motherboard basic properties | ||
| Manufacturer | MSI | |
| chipset | AMD B650 | |
| form factor | Micro-ATX | |
| motherboard processor | ||
| processor family | AMD | |
| processor socket | Socket AM5 | |
| Supported processors | Ryzen 7000, Ryzen 8000G - Phoenix2, Ryzen 8000G - Phoenix, Ryzen 9000 | |
| motherboard memory | ||
| number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| storage type | DDR5 | |
| supported memory clock | DDR5-5200 (Ryzen 7000), DDR5-5200 (Ryzen 8000G - Phoenix), DDR5-5200 (Ryzen 8000G - Phoenix2), DDR5-5600 (Ryzen 9000) | |
| motherboard expansion slots | ||
| PCI-Express x16 (total) | 3x | |
| PCI-Express 4.0 x16 | 1x | |
| PCI-Express x1 | 2x (3.0) | |
| M.2 | 1x | |
| motherboard external connections | ||
| DisplayPort | Yes | |
| HDMI | Yes | |
| USB 3.1 Type-A | 3x | |
| USB 3.1 Type-C | 1x | |
| USB 3.0 | 4x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 3x | |
| motherboard internal connections | ||
| SATA 6 GB/s | 4x | |
| USB 3.1 header | 1x (Type-C) | |
| USB 3.0 header | 1 x | |
| USB 2.0 header | 2 x | |
| Serial | Yes | |
| TPM header | Yes | |
| Chassis Intrusion Header | Yes | |
| MSI tuning controller header 5-pin | Yes | |
| RAID | 0/1/10 | |
| power connections | 1 x 24-pin ATX, 2 x 8-pin ATX 12V | |
| audio channels | 7.1 | |
| audio codec | Realtek ALC897 | |
| motherboard cooling | ||
| CPU fan 4-pin | 1x | |
| case fan 4-pin | 3x | |
| pump 4-pin | 1x | |
| motherboard lighting | ||
| RGB header 4-pin | 2x | |
| ARGB header 3-pin | 2x | |
| motherboard network | ||
| transfer rate | 10/100/1000 Mb/s | |
| Wi-Fi | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.3 | |
| motherboard features | ||
| M.2 passive cooler | 2x | |
| Diagnostic LED | Yes | |
| IO panel integrated | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| item condition | New | |
