| series - motherboards |
| series | AsRock TAICHI series |
|
| motherboard basic properties |
| Manufacturer | ASRock |
| chipset | AMD X870E |
| form factor | E-ATX |
|
| motherboard processor |
| processor family | AMD |
| processor socket | Socket AM5 |
| Supported processors | Ryzen 9000, Ryzen 8000/8000G, Ryzen 7000 |
| Notice | up to 8200 MHz |
|
| motherboard memory |
| number of DIMM slots | 4x |
| Maximum main memory | 256 GB |
| storage type | DDR5 |
| Non-ECC, Un-buffered | Yes |
|
| motherboard expansion slots |
| PCI-Express x16 (total) | 2x |
| PCI-Express 5.0 x16 | 2x |
| M.2 | 4x |
|
| motherboard external connections |
| HDMI | Yes |
| USB 4.0 | 2x (with DisplayPort 1.4a) |
| USB 3.1 Type-A | 5x |
| USB 3.0 | 3x |
| USB 2.0 | 2x |
| Ethernet (LAN) | 1 x |
| 3.5mm jack | 2x |
| Toslink/S/PDIF (optical) | Yes |
|
| motherboard internal connections |
| SATA 6 GB/s | 6x |
| USB 3.2 header | 1x |
| USB 3.0 header | 2 x |
| USB 2.0 header | 2 x |
| TPM header | Yes |
| RAID | 0/1/10 |
| power connections | 1x 24-pin ATX, 2x 8-pin EPS12V |
| audio channels | 7.1 |
| audio codec | Realtek ALC4082, DAC (ESS ES9219Q) |
|
| motherboard cooling |
| CPU fan 4-pin | 2x |
| case fan 4-pin | 4x |
| pump 4-pin | 1x |
| thermal sensor | 2x |
|
| motherboard lighting |
| RGB header 4-pin | 1x |
| ARGB header 3-pin | 3x |
|
| motherboard network |
| LAN controller | RJ-45 5Gb LAN (Realtek RTL8126CG |
| transfer rate | 10/100/1000/2500/5000 Mb/s |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) |
| Bluetooth | 5.4 |
|
| motherboard features |
| USB BIOS Flashback | Yes |
| M.2 passive cooler | 4x |
| Diagnostic LED | Yes |
| IO panel integrated | Yes |
| Audio+solid capacitors | Yes |
|
| Condition |
| item condition | New |
