The ASRock B850 Pro RS WiFi motherboard is designed for performance and versatility. It supports AMD B850 chipset and features a Socket AM5 for compatibility with Ryzen 7000/8000/9000 Series processors. This motherboard offers a robust power design with a 14+2+1 Phase Power Design, reinforced PCIe slots, and an aluminum heatsink design to ensure stability during demanding tasks.
With support for high-speed DDR5 SDRAM up to 4000 MHz (O.C.) and a dual-channel memory architecture, this motherboard enables efficient multitasking and high-performance computing. It comes equipped with multiple M.2 and SATA interfaces, including 2 Hyper M.2 and 1 Blazing M.2 slots, providing fast storage options. Additionally, integrated Wi-Fi 6E and Bluetooth 5.2 capabilities ensure seamless connectivity options for various devices.
With support for high-speed DDR5 SDRAM up to 4000 MHz (O.C.) and a dual-channel memory architecture, this motherboard enables efficient multitasking and high-performance computing. It comes equipped with multiple M.2 and SATA interfaces, including 2 Hyper M.2 and 1 Blazing M.2 slots, providing fast storage options. Additionally, integrated Wi-Fi 6E and Bluetooth 5.2 capabilities ensure seamless connectivity options for various devices.
processor
Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processors: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory type: DIMM
Memory channels: Dual channel
ECC compatibility: ECC
Maximum RAM: 256 GB
Memory controller
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID Level: 0, 1, 10
Internal I/O ports
Number of USB 2.0 ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) ports: 2
USB 3.2 Gen 2x2 ports: 1
SATA III ports: 4
Front panel audio connector: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of chassis fan connectors: 4
EPS power connector (8-pin): Yes
Number of EPS power connectors (4-pin): 2
TPM connection: Yes
RGB LED header: Yes
I/O ports on the back
Number of USB 2.0 ports: 6
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports: 1
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
Line-in: Yes
Microphone input: Yes
WiFi AP antenna socket: 2
network
Ethernet/LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN Controller: Dragon RTL8125BG
Wi-Fi: Yes
Top WLAN standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Bluetooth version: 5.2
Features
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Audio channels: 7.1 channels
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: AMD
Supported Windows operating systems: Windows 10 x64, Windows 11 x64
Expansion slots
PCI Express x16 slots (Gen 4.x): 1
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 1
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Weight and dimensions
Width: 305 mm
Depth: 244 mm
Scope of delivery
Included cables: SATA
Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processors: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
memory
Supported memory types: DDR5-SDRAM
Number of memory slots: 4
Memory type: DIMM
Memory channels: Dual channel
ECC compatibility: ECC
Maximum RAM: 256 GB
Memory controller
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
RAID Level: 0, 1, 10
Internal I/O ports
Number of USB 2.0 ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) ports: 2
USB 3.2 Gen 2x2 ports: 1
SATA III ports: 4
Front panel audio connector: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of CPU fan connectors: 2
Number of chassis fan connectors: 4
EPS power connector (8-pin): Yes
Number of EPS power connectors (4-pin): 2
TPM connection: Yes
RGB LED header: Yes
I/O ports on the back
Number of USB 2.0 ports: 6
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports: 1
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
Line-in: Yes
Microphone input: Yes
WiFi AP antenna socket: 2
network
Ethernet/LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN Controller: Dragon RTL8125BG
Wi-Fi: Yes
Top WLAN standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Bluetooth version: 5.2
Features
Motherboard chipset: AMD B850
Audio chip: Realtek ALC897
Audio channels: 7.1 channels
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: AMD
Supported Windows operating systems: Windows 10 x64, Windows 11 x64
Expansion slots
PCI Express x16 slots (Gen 4.x): 1
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 1
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Weight and dimensions
Width: 305 mm
Depth: 244 mm
Scope of delivery
Included cables: SATA
