Intel S1851 CORE ULTRA 5 235 TRAY

processor
Processor manufacturer: Intel
Processor generation: Intel Core Ultra (Series 2)
Processor: 235
Processor family: Intel Core Ultra 5
Number of processor cores: 14
Processor socket: LGA 1851 (Socket V1)
Processor operating modes: 64-bit
Performance cores: 6
Efficient cores: 8
Processor boost frequency: 5 GHz
Performance Core Boost Frequency: 5 GHz
Performance Base frequency of the core: 3.4 GHz
Efficient core boost frequency: 4.4 GHz
Efficient base frequency of the core: 2.9 GHz
Processor cache: 24 MB
Processor Cache Type: Smart Cache
Packaging type: Insert
Base power of the processor: 65 W
Maximum turbo power: 121 W
CPU-supported AI software frameworks: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Maximum number of DMI lanes: 8
Processor codename: Arrow Lake
ARK processor identification: 241674
Neural Processing Unit (NPU)
Neural Processing Unit (NPU): Intel AI Boost
Feature: Sparsity Support
Feature: Support for Windows Studio effects
AI software frameworks supported by the NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance up to: 27 tera operations per second
NPU performance up to: 13 tera-operations per second
GPU performance up to: 6 tera operations per second
memory
Maximum internal storage supported by the processor: 192 GB
Memory types supported by the processor: DDR5-SDRAM
Memory clock speeds supported by the processor: 6400 MHz
Memory channels: Dual channel
Feature: ECC
graphic
Feature: Built-in graphics adapter
Built-in graphics card model: Intel Graphics
On-board graphics adapter supported outputs: HDMI 2.1, Embedded DisplayPort (eDP) 1.4b, DisplayPort 2.1
On-board graphics adapter base frequency: 300 MHz
Maximum dynamic frequency of the on-board graphics adapter: 2000 MHz
Number of supported displays (on-board graphics): 4
On-board graphics adapter DirectX Version: 12.0
On-board graphics adapter OpenGL version: 4.5
On-board graphics adapter refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics adapter refresh rate at maximum resolution (eDP - integrated flat panel display): 60 Hz
On-board graphics adapter refresh rate at maximum resolution (HDMI): 60 Hz
On-board graphics adapter device ID: 0x7D67
Separate graphics card model: Not available
Xe cores: 3
Features
Feature: Execute Disable Bit
Feature: Idle states
Feature: Thermal monitoring technologies
Market segment: Desktop
Terms of Use: Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes: 24
PCI Express Slots Version: 4.0, 5.0
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Scalability: 1S
Direct Media Interface (DMI) Revision: 4.0
Processor features
Intel® Turbo Boost Technology: 2.0
Feature: Intel® Quick Sync Video Technology
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Enhanced Intel SpeedStep Technology
Feature: Intel® Trusted Execution Technology
Feature: Intel® Speed Shift Technology
Features: Intel® Thunderbolt 4
Feature: Intel® Control-flow Enforcement Technology (CET)
Feature: Intel® Thread Director
Feature: Intel® VT-x with Extended Page Tables (EPT)
Feature: Intel® Secure Key
Feature: Intel® Active Management Technology (Intel® AMT)
Feature: Intel® OS Guard
Feature: Intel® 64
Feature: Intel® Virtualization Technology (VT-X)
Feature: Intel® Virtualization Technology for Direct I/O (VT-d)
Feature: Intel® Boot Guard
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Volume Management Device (VMD)
Feature: Mode-Based Execute Control (MBE)
Feature: Intel® Standard Manageability (ISM)
Feature: Intel® One-Click Recovery
Feature: Intel® Stable IT Platform Program (SIPP)
Feature: Intel® Remote Platform Erase (RPE)
Feature: Intel® Virtualization Technology with Redirection Protection (VT-rp)
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Feature: Intel vPro® Enterprise Platform Entitlement
Feature: Intel® Threat Detection Technology (TDT)
Feature: Intel® Hardware Shield Eligibility
Feature: Intel® Total Memory Encryption - Multi Key
Operating conditions
Maximum operating temperature: 105 °C
Technical details
OpenCL version: 3.0
Start date: Q1 “25
Status: Launched
Other functions
Buffer storage L2: 26624 KB
Maximum RAM: 192 GB
Graphical output: DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
