INTEL Core i5-12600K 3.7GHz 6+4 cores 20MB cache socket 1700 (boxed without fan)

processor
Processor family: Intel® Core™ i5
Number of processor cores: 10
Processor socket: LGA 1700
box: yes
Processor manufacturer: Intel
Processor: i5-12600K
Processor operating modes: 64-bit
Processor generation: 12th generation Intel® Core™ i5 processors
Component for: PC
Processor threads: 16
Power cores: 6
Efficient cores: 4
Processor Boost Frequency: 4.9GHz
Performance Core Boost Frequency: 4.9GHz
Performance Core base frequency: 3.7 GHz
Efficient Core Boost Frequency: 3.6GHz
Core Efficient Base Frequency: 2.8GHz
Processor cache: 20 MB
Processor Cache Type: Smart Cache
Processor base power: 125 W
Maximum Turbo Power: 150W
Bus type: DMI4
Maximum number of DMI tracks: 8
Memory bandwidth supported by the processor (max): 76.8 GB/s
Processor code name: Alder Lake
ARK processor identification: 134589

Storage
Memory channels: Dual channel
Maximum internal memory supported by the processor: 128 GB
Memory types supported by the processor: DDR4-SDRAM, DDR5-SDRAM
ECC: Yes
Memory bandwidth (max): 76.8 GB/s

graphic
Built-in graphics adapters: Yes
Discrete Graphics Adapter: No
On-board graphics adapter model: Intel UHD Graphics 770
Dedicated graphics adapter model: Not available
On-board graphics adapter supported outputs: HDMI 2.1, DisplayPort 1.4a, Embedded DisplayPort (eDP) 1.4b
On-board graphics adapter base frequency: 300 MHz
Maximum dynamic frequency of on-board graphics adapters: 1450 MHz
Number of supported displays (on-board graphics): 4
On-board graphics adapter DirectX version: 12.0
On-board graphics adapter OpenGL version: 4.5
Maximum resolution of the on-board graphics adapter (DisplayPort): 7680 x 4320 pixels
Maximum resolution of the on-board graphics adapter (eDP - integrated flat screen): 5120 x 3200 pixels
Integrated graphics adapter maximum resolution (HDMI): 4096 x 2160 pixels
Refresh rate of the on-board graphics adapter at maximum resolution (DisplayPort): 60 Hz
Refresh rate of the on-board graphics adapter at maximum resolution (eDP - integrated flat screen): 120 Hz
Refresh rate of the on-board graphics adapter at maximum resolution (HDMI): 60 Hz
On-board graphics adapter Device ID: 0x4680
Number of calculators: 32

characteristics
Execute Disable Bit: Yes
Idle Conditions: Yes
Thermal Monitoring Technologies: Yes
Market Segment: Desktop
Terms of Use: PC/Client/Tablet
Maximum number of PCI Express lanes: 20
PCI Express Slots Version: 5.0, 4.0
PCI Express configurations: 1x16+1x4, 2x8+1x4
Supported instruction sets: SSE4.1, SSE4.2, AVX 2.0
Scalability: 1S
CPU configuration (max): 1
Embedded Options Available: No
Thermal solution specification: PCG 2020A
Export Control Classification Number (ECCN): 5A992CN3
Automated Tracking Commodity Classification System (CCATS): G167599

Processor specifics
Intel® Hyper-Threading Technology (Intel® HT Technology): Yes
Intel® Turbo Boost Technology: 2.0
Intel® Quick Sync Video Technology: Yes
Intel® Clear Video HD Technology for (Intel® CVT HD): Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Trusted Execution Technology: Yes
Intel® Speed Shift Technology: Yes
Intel® Total Memory Encryption: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Intel® VT-x with Extended Page Tables (EPT): Yes
Intel® Secure Key: Yes
Intel® Active Management Technology (Intel® AMT): Yes
Intel Stable Image Platform Program (SIPP): Yes
Intel® OS Guard: Yes
Intel® 64: Yes
Intel® Virtualization Technology (VT-X): Yes
Intel® Virtualization Technology for Direct I/O (VT-d): Yes
Intel Turbo Boost Max Technology 3.0: No
Intel® Optane™ Memory Ready: Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost): Yes
Intel® Volume Management Device (VMD): Yes
Mode-Based Execute Control (MBE): Yes
Intel® vPro™ Platform Eligibility: Yes
Intel® Standard Manageability (ISM): Yes
Intel® One Click Recovery: Yes
Intel® Virtualization Technology with Redirect Protection (VT-RP): Yes
Intel vPro® Enterprise Platform Eligibility: Yes
Intel® Threat Detection Technology (TDT): Yes
Intel® Hardware Shield Eligibility: Yes
Intel® Total Memory Encryption - Multi Key: Yes

operating conditions
Junction: 100°C

weight and dimensions
Processor Package Size: 45 x 37.5 mm

Other functions
RAM memory maximum: 128 GB
Graphic output: eDP 1.4b, DP 1.4a, HDMI 2.1
