The HPE Networking Instant On Switch 1930 series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1 G SFP slots on 8-port model and 1 G/10 G SFP+ slots on 24-/48 G models for fiber connectivity.
Management functions
Switch type: Managed
Switch level: L2+
Quality of Service (QoS) Support: Yes
Web-based management: Yes
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of combo SPF connectors: 2
network
Network standard: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support: No
Copper Ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Full duplex: Yes
Data flow control support: Yes
Link Aggregation: Yes
Rate limit: Yes
Auto MDI/MDI-X: Yes
Spannbaum protocol: Yes
Auto-scan: Yes
VLAN support: Yes
Number of VLANs: 256
Data transmission
Routing/switching capacity: 20 Gbit/s
Pass: 14.8 MPPS
MAC address table: 8000 entries
Waiting time (10-100 Mbps): 5.2 µs
Waiting time (1 Gbps): 3 µs
Jumbo Frames Support: Yes
Data packet buffer: 1.5 MB
Security
IGMP snooping: Yes
SSH/SSL support: Yes
design
Rack mounting: Yes
Stackable: No
Form factor: 1U
Product color: White
Services
Processor: ARM Cortex-A9
Processor clock speed: 800 MHz
Memory type: SDRAM
Storage capacity: 512 MB
Flash memory: 256 MB
energy
Energy source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max.): 150.2 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) power consumption: 124 W
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 95%
Weight and dimensions
Width: 254 mm
Depth: 254 mm
Height: 43.9 mm
Weight: 1.16 kg
Logistics data
Commodity tariff number (HS): 85176990
Switch type: Managed
Switch level: L2+
Quality of Service (QoS) Support: Yes
Web-based management: Yes
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of combo SPF connectors: 2
network
Network standard: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support: No
Copper Ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring: Yes
Full duplex: Yes
Data flow control support: Yes
Link Aggregation: Yes
Rate limit: Yes
Auto MDI/MDI-X: Yes
Spannbaum protocol: Yes
Auto-scan: Yes
VLAN support: Yes
Number of VLANs: 256
Data transmission
Routing/switching capacity: 20 Gbit/s
Pass: 14.8 MPPS
MAC address table: 8000 entries
Waiting time (10-100 Mbps): 5.2 µs
Waiting time (1 Gbps): 3 µs
Jumbo Frames Support: Yes
Data packet buffer: 1.5 MB
Security
IGMP snooping: Yes
SSH/SSL support: Yes
design
Rack mounting: Yes
Stackable: No
Form factor: 1U
Product color: White
Services
Processor: ARM Cortex-A9
Processor clock speed: 800 MHz
Memory type: SDRAM
Storage capacity: 512 MB
Flash memory: 256 MB
energy
Energy source: AC
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max.): 150.2 W
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) power consumption: 124 W
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 95%
Weight and dimensions
Width: 254 mm
Depth: 254 mm
Height: 43.9 mm
Weight: 1.16 kg
Logistics data
Commodity tariff number (HS): 85176990
