• Plug-and-play switches that work with Instant On APs • Configure and manage multiple switches via the Instant On app • No additional license or subscription fees • Automatic denial-of-service (DOS) monitoring • Limited lifetime warranty and industry-leading support
Management functions
Switch type: Managed
Switch level: L2+
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Feature: Cloud-managed
Connections and interfaces
Number of base-switching RJ-45 Ethernet ports: 24
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of SFP+ module slots: 4
network
Feature: 10G support
Feature: Port Mirroring
Feature: Full duplex
Feature: Support data flow control
Property: Link Aggregation
Property: Rate Limiting
Feature: Auto MDI/MDI-X
Property: Spanning Tree Protocol
Feature: Auto-scanning
Feature: VLAN support
Data transfer
Routing/switching capacity: 128 Gbit/s
Pass: 95.23 Mpps
MAC address table: 16000 entries
Latency (10-100 Mbps): 4.7 µs
Latency (1 Gbps): 2.4 µs
Latency (10 Gbps): 1.3 µs
Feature: Jumbo Frames Support
Data packet buffer memory: 1.5 MB
Security
DHCP functions: DHCP client
Property: Access Control List
Property: IGMP snooping
Feature: SSH/SSL support
design
Feature: Rack mounting
Form factor: 1U
Product color: white
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock frequency: 800 MHz
Memory type: SDRAM / Flash
Storage capacity: 512 MB
Flash memory: 256 MB
energy
Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max.): 280 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Total Power over Ethernet (PoE): 195 W
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 95%
Operating altitude: 0 - 3048 m
Weight and dimensions
Width: 442.5 mm
Depth: 264.7 mm
Height: 43.9 mm
Weight: 3.49 kg
Switch type: Managed
Switch level: L2+
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Feature: Cloud-managed
Connections and interfaces
Number of base-switching RJ-45 Ethernet ports: 24
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of SFP+ module slots: 4
network
Feature: 10G support
Feature: Port Mirroring
Feature: Full duplex
Feature: Support data flow control
Property: Link Aggregation
Property: Rate Limiting
Feature: Auto MDI/MDI-X
Property: Spanning Tree Protocol
Feature: Auto-scanning
Feature: VLAN support
Data transfer
Routing/switching capacity: 128 Gbit/s
Pass: 95.23 Mpps
MAC address table: 16000 entries
Latency (10-100 Mbps): 4.7 µs
Latency (1 Gbps): 2.4 µs
Latency (10 Gbps): 1.3 µs
Feature: Jumbo Frames Support
Data packet buffer memory: 1.5 MB
Security
DHCP functions: DHCP client
Property: Access Control List
Property: IGMP snooping
Feature: SSH/SSL support
design
Feature: Rack mounting
Form factor: 1U
Product color: white
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock frequency: 800 MHz
Memory type: SDRAM / Flash
Storage capacity: 512 MB
Flash memory: 256 MB
energy
Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Power consumption (max.): 280 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Total Power over Ethernet (PoE): 195 W
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 95%
Operating altitude: 0 - 3048 m
Weight and dimensions
Width: 442.5 mm
Depth: 264.7 mm
Height: 43.9 mm
Weight: 3.49 kg
