The HPE Aruba Networking CX 6000 Switch Series is a modern family of entry level access switches ideal for branch offices, midsize businesses, and small enterprises. Designed for reliable, simple, and secure access, this switch family provides a convenient and cost-effective wired access solution for networks supporting Internet of Things (IoT), mobile, and cloud applications. Prepare your network for future demands with a powerful ASIC and HPE Aruba Networking CX Switch Operating System for a consistent, and efficient operator experience. This fully-managed series has convenient built-in uplinks with up to 740W of Class 4 PoE to support IoT devices such as security cameras and wireless APs. A compact and fanless model is ideal for use in quiet, small workspaces. The CX 6000 series is easy to deploy and use with flexible management choices, allowing the ideal fit for your business and network environment.
Management functions
Switch type: Managed
Switch level: L3
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Feature: Cloud-managed
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 12
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of SFP module slots: 2
Console port: USB
network
Feature: Port mirroring
Feature: Support for data flow control
Feature: Link Aggregation
Feature: Auto MDI/MDI-X
Feature: Spannbaum protocol
Feature: VLAN support
Data transmission
Routing/switching capacity: 32 Gbit/s
Pass: 23.8 MPPS
MAC address table: 8192 entries
Waiting time (1 Gbps): 2.3 µs
Feature: Static route
Data packet buffer: 12.38 MB
Security
DHCP functions: DHCP client
Feature: Access Control List
Feature: IGMP snooping
Authentication: MAC-based authentication
Multicast functions
Feature: Multicast support
Protocols
IPv4 & IPv6 functions: IPv4/IPv6 access-control list (ACL)
IPv4 FIB entries: 256
IPv6 FIB entries: 128
design
Feature: Rack mounting
Form factor: 1U
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock speed: 1016 MHz
Memory type: DDR3-SDRAM
Storage capacity: 4096 MB
Flash memory: 16384 MB
energy
Energy source: AC
Feature: Power supply included
AC input voltage: 200 - 240 V
AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Total Power over Ethernet (PoE) power consumption: 139 W
Operating conditions
Operating temperature: 0 - 45 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 90%
Weight and dimensions
Width: 44 mm
Depth: 254 mm
Height: 255 mm
Weight: 2.8 kg
Logistics data
Commodity tariff number (HS): 85176990
Switch type: Managed
Switch level: L3
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Feature: Cloud-managed
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 12
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of SFP module slots: 2
Console port: USB
network
Feature: Port mirroring
Feature: Support for data flow control
Feature: Link Aggregation
Feature: Auto MDI/MDI-X
Feature: Spannbaum protocol
Feature: VLAN support
Data transmission
Routing/switching capacity: 32 Gbit/s
Pass: 23.8 MPPS
MAC address table: 8192 entries
Waiting time (1 Gbps): 2.3 µs
Feature: Static route
Data packet buffer: 12.38 MB
Security
DHCP functions: DHCP client
Feature: Access Control List
Feature: IGMP snooping
Authentication: MAC-based authentication
Multicast functions
Feature: Multicast support
Protocols
IPv4 & IPv6 functions: IPv4/IPv6 access-control list (ACL)
IPv4 FIB entries: 256
IPv6 FIB entries: 128
design
Feature: Rack mounting
Form factor: 1U
Services
Feature: Built-in processor
Processor: ARM Cortex-A9
Processor clock speed: 1016 MHz
Memory type: DDR3-SDRAM
Storage capacity: 4096 MB
Flash memory: 16384 MB
energy
Energy source: AC
Feature: Power supply included
AC input voltage: 200 - 240 V
AC input frequency: 50 - 60 Hz
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Total Power over Ethernet (PoE) power consumption: 139 W
Operating conditions
Operating temperature: 0 - 45 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 15 - 95%
Storage humidity: 15 - 90%
Weight and dimensions
Width: 44 mm
Depth: 254 mm
Height: 255 mm
Weight: 2.8 kg
Logistics data
Commodity tariff number (HS): 85176990
