| Series - Mainboards |
| series | Gigabyte AORUS Elite |
|
| Basic motherboard characteristics |
| Chipset manufacturer | AMD |
| Manufacturer | GIGABYTE |
| Chipset | AMD B850 |
| Form factor | µATX |
| BIOS type | 1x 32MB (256Mb) |
| Dimensions | (Micro-ATX) 244 mm × 244 mm |
|
| Motherboard processor |
| Processor family | AMD |
| processor socket | Socket AM5 |
| Supported processors | Ryzen 9000, Ryzen 8000G, Ryzen 7000 |
|
| Motherboard memory |
| Number of DIMM slots | 4x |
| Maximum main memory | 256 GB |
| Storage type | DDR5 |
| Non-ECC, Un-buffered | Yes |
| supported memory clock | up to 8200 MHz |
|
| Motherboard expansion slots |
| PCI-Express x16 (total) | 2x |
| PCI-Express 5.0 x16 | 1x |
| PCI-Express 3.0 x16 | 1x |
| M.2 | 2x |
|
| Motherboard External Connectors |
| DisplayPort | 1x |
| USB 3.1 Type-A | 2x |
| USB 3.1 Type-C | 1x |
| USB 3.0 | 5x |
| USB 2.0 | 4x |
| Ethernet (LAN) | 1 x |
| 3.5mm jack | 2x |
| Toslink/S/PDIF (optical) | Yes |
|
| Internal motherboard connectors |
| SATA 6 GB/s | 4x |
| USB 3.2 Header | 1x |
| USB 3.0 Header | 1 x |
| USB 2.0 Header | 2 x |
| TPM header | Yes |
| other | 1x HDMI 1.4 (iGPU) |
| RAID | 0/1/10 |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V |
| Audio channels | 7.1 |
| Audio codec | Realtek ALC897 |
|
| Motherboard cooling |
| CPU fan 4-pin | 1x |
| 4-pin case fan | 3x |
| 4-pin pump | 2x |
|
| Motherboard lighting |
| RGB header 4-pin | 1x |
| ARGB 3-pin header | 3x |
| Lighting color | RGB |
| LED compatibility | Gigabyte RGB Fusion 2.0 |
|
| Motherboard network |
| LAN Controller | 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG) |
| Transfer rate | 10/100/1000/2500 Mb/s |
| Wi-Fi | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) |
| Bluetooth | 5.3 |
|
| Motherboard features |
| USB BIOS Flashback | Yes |
| M.2 passive cooler | 2x |
| Diagnostic LED | Yes |
| Integrated I/O shield | Yes |
| Audio + solid capacitors | Yes |
|
| Condition |
| Item condition | New |
