The GIGABYTE B850M FORCE WIFI6E motherboard is designed for high-performance computing, featuring connectivity and support for current technology standards. With a micro ATX form factor, it efficiently utilizes space while providing room for upgrades. It supports dual-channel DDR5 SDRAM, offering speeds up to 9600 MT/s through overclocking, ensuring your system can handle demanding applications and multitasking.
Equipped with USB 3.2 Gen 2 and USB-C 3.2 Gen 1 ports, the motherboard ensures fast data transfer rates and compatibility with modern devices. The 2.5 Gigabit Ethernet and integrated Wi-Fi 6E provide robust network options, catering to both wired and wireless connections. With built-in high definition audio capabilities and various expansion slots, this motherboard is suitable for gamers and professionals seeking reliability and performance.
Equipped with USB 3.2 Gen 2 and USB-C 3.2 Gen 1 ports, the motherboard ensures fast data transfer rates and compatibility with modern devices. The 2.5 Gigabit Ethernet and integrated Wi-Fi 6E provide robust network options, catering to both wired and wireless connections. With built-in high definition audio capabilities and various expansion slots, this motherboard is suitable for gamers and professionals seeking reliability and performance.
| Basic motherboard characteristics | ||
| Chipset manufacturer | AMD | |
| Manufacturer | GIGABYTE | |
| Chipset | AMD B850 | |
| Form factor | µATX | |
| BIOS type | 1x 32MB (256Mb) | |
| Dimensions | (Micro-ATX) 244 mm × 244 mm | |
| Motherboard processor | ||
| Processor family | AMD | |
| processor socket | Socket AM5 | |
| Supported processors | Ryzen 9000, Ryzen 8000G, Ryzen 7000 | |
| Motherboard memory | ||
| Number of DIMM slots | 2x | |
| Maximum main memory | 128 GB | |
| Storage type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| supported memory clock | up to 9600 MHz | |
| Motherboard expansion slots | ||
| PCI-Express x16 (total) | 1x | |
| PCI-Express 5.0 x16 | 1x | |
| M.2 | 3x | |
| Motherboard External Connectors | ||
| DisplayPort | 1x | |
| HDMI | 1x | |
| USB 3.1 Type-A | 1x | |
| USB 3.0 | 3x (1x Type C) | |
| USB 2.0 | 2x | |
| PS/2 | 1 x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 3x | |
| Internal motherboard connectors | ||
| SATA 6 GB/s | 4x | |
| USB 3.0 Header | 2 x | |
| USB 2.0 Header | 2 x | |
| TPM header | Yes | |
| RAID | 0/1/10 | |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V | |
| Audio channels | 7.1 | |
| Audio codec | Realtek ALC897 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 1x | |
| 4-pin case fan | 1x | |
| 4-pin pump | 2x | |
| Motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB 3-pin header | 3x | |
| LED compatibility | Gigabyte RGB Fusion 2.0 | |
| Motherboard network | ||
| LAN Controller | 1x RJ-45 (2.5GBase-T, Realtek RTL8125BG) | |
| Transfer rate | 10/100/1000/2500 Mb/s | |
| Wi-Fi | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.3 | |
| Motherboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 2x | |
| Diagnostic LED | Yes | |
| Integrated I/O shield | Yes | |
| Audio + solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
