Chipset: AMD B650 / Processor socket: Socket AM5 / Memory support: 2x DDR5 / Form factor: Mini-ITX
| Mainboard basic features | ||
| Manufacturer | GIGABYTE | |
| Chipset | Intel B650 | |
| Form factor | Mini ITX | |
| BIOS Type | 1x 32MB (256Mb) | |
| Mainboard processor | ||
| Processor family | AMD | |
| Processor socket | Socket AM5 | |
| Supported processors | Ryzen 8000G, Ryzen 7000 | |
| Notice | without TDP restriction | |
| Motherboard memory | ||
| Number of DIMM slots | 2x | |
| Maximum main memory | 96GB | |
| Storage type | DDR5 | |
| Motherboard expansion slots | ||
| PCI Express x16 (total) | 1x | |
| PCI Express 4.0 x16 | 1x | |
| M.2 | 2x | |
| Mainboard external connections | ||
| DisplayPort | Yes | |
| HDMI | Yes | |
| USB 3.1 Type A | 2x | |
| USB 3.1 Type C | 1x | |
| USB3.0 | 2x | |
| USB2.0 | 2x | |
| 3.5mm jack | 2x | |
| Mainboard internal connections | ||
| USB 3.2 headers | 1x | |
| USB 3.0 headers | 1x | |
| TPM header | Yes | |
| Chassis Intrusion Header | Yes | |
| RAID | 0/1/10 | |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V | |
| Audio channels | 7.1 | |
| Audio codec | Realtek ALC4080 | |
| Mainboard cooling | ||
| CPU fan 4-pin | 1x | |
| Pump 4-Pin | 1x | |
| Mainboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB header 3-pin | 1x | |
| Mainboard network | ||
| LAN Controller | 2.5GBase-T (Intel I225-V) | |
| WIRELESS INTERNET ACCESS | Wi-Fi 6E (WLAN 802.11a/b/g/n/ac/ax) | |
| Bluetooth | 5.2 | |
| Mainboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 1x | |
| IO panel integrated | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
