Digitus 8-Port Gigabit Ethernet Network PoE Switch, Industrial, L2 Managed, 4 SFP Uplinks, Managed, L2, Gigabit Ethernet (10/100/1000), Full Duplex. Digitus 8-Port Gigabit Ethernet Network PoE Switch, Industrial, L2 Managed, 4 SFP Uplinks. Switch Type: Managed, Switch Level: L2. Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000), Number of Basic Switching RJ-45 Ethernet Ports: 8, Console Port: RJ-45. Full Duplex. MAC Address Table: 8000 Entries, Routing/Switching Capacity: 24 Gbps. Network standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... DC input voltage: 48 - 57 V
Podijelite:
The DN-651139 industrial network switch offers eight 10/100/1000 Mbps RJ45 ports and four Gigabit combo ports. RJ45 ports 1-8 support PoE power supply with a maximum of 30 W per port.
- Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x standards
- PoE supports the IEEE 802.3af/at standards and offers a maximum power output of 30 W per port.
- The distance between data transmission and power supply is 100 meters.
- Supports IEEE802.3x full-duplex flow control and backpressure half-duplex flow control; panel displays monitor the operating status and assist in fault analysis.
- High-energy aluminum alloy roof heat conduction groove design.
- Supports one-click ring networking and one-click storm suppression, with redundancy and high reliability;
- Highly reliable design, supports traditional STP/MSTP/RSTP 2-Layer Link Protection technology.
- Supports static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increasing link bandwidth, improving connection reliability and simultaneously achieving load balancing and link backup.
- Flexible and convenient management and maintenance. Supports various management modes, such as console, Telnet and SSH.
- Supports web administration, which is simple and efficient, simplifying installation and troubleshooting for technical and maintenance personnel. Supports file upload and download management via TFTP.
The DN-651139 industrial network switch offers eight 10/100/1000 Mbps RJ45 ports and four Gigabit combo ports. RJ45 ports 1-8 support PoE power delivery with a maximum of 30 W per port. The DN651139 features excellent security, QoS, and comprehensive VLAN functionality. It also includes a ring network function, allowing you to configure a ring network. With this function, the switches manually form a ring network topology. The ring network is redundant, highly reliable, and does not disrupt data transmission if a connection is interrupted. The device features a fanless, energy-efficient design that is easy to use, compact, and aesthetically pleasing. It is also easy to install. The product complies with Ethernet standards, includes surge and static protection, and operates in a temperature range of -40°C to 75°C. This guarantees stable performance, security, and reliability. The DN651139 can be used in various broadband data transmission sectors such as intelligent transportation, telecommunications, security, financial securities, customs, and others.
- Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x standards
- PoE supports the IEEE 802.3af/at standards and offers a maximum power output of 30 W per port.
- The distance between data transmission and power supply is 100 meters.
- Supports IEEE802.3x full-duplex flow control and backpressure half-duplex flow control; panel displays monitor the operating status and assist in fault analysis.
- High-energy aluminum alloy roof heat conduction groove design.
- Supports one-click ring networking and one-click storm suppression, with redundancy and high reliability;
- Highly reliable design, supports traditional STP/MSTP/RSTP 2-Layer Link Protection technology.
- Supports static convergence and dynamic convergence (LACP) 2 convergence modes, effectively increasing link bandwidth, improving connection reliability and simultaneously achieving load balancing and link backup.
- Flexible and convenient management and maintenance. Supports various management modes, such as console, Telnet and SSH.
- Supports web administration, which is simple and efficient, simplifying installation and troubleshooting for technical and maintenance personnel. Supports file upload and download management via TFTP.
The DN-651139 industrial network switch offers eight 10/100/1000 Mbps RJ45 ports and four Gigabit combo ports. RJ45 ports 1-8 support PoE power delivery with a maximum of 30 W per port. The DN651139 features excellent security, QoS, and comprehensive VLAN functionality. It also includes a ring network function, allowing you to configure a ring network. With this function, the switches manually form a ring network topology. The ring network is redundant, highly reliable, and does not disrupt data transmission if a connection is interrupted. The device features a fanless, energy-efficient design that is easy to use, compact, and aesthetically pleasing. It is also easy to install. The product complies with Ethernet standards, includes surge and static protection, and operates in a temperature range of -40°C to 75°C. This guarantees stable performance, security, and reliability. The DN651139 can be used in various broadband data transmission sectors such as intelligent transportation, telecommunications, security, financial securities, customs, and others.
Management functions
Switch type: Managed
Switch level: L2
Quality of Service (QoS) Support: Yes
Web-based management: Yes
ARP inspection: Yes
System event log: Yes
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of combo SPF connectors: 4
Console port: RJ-45
network
Network standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support: No
Copper Ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
Supported cable types: Cat3, Cat4, Cat5, Cat5e
Port mirroring: Yes
Full duplex: Yes
Half-duplex: Yes
Data flow control support: Yes
Broadcast storm control: Yes
Spannbaum protocol: Yes
Self-learning of MAC addresses supported: Yes
VLAN support: Yes
Virtual LAN functions: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
optical fibers
Transmission distance (max): 0.1 km
Data transmission
Routing/switching capacity: 24 Gbit/s
Transfer rate: 17.86 MPPS
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo Frames Support: Yes
Jumbo frames: 9216
Data packet buffer: 4.1 MB
Security
DHCP functions: DHCP relay, DHCP snooping
Access Control List: Yes
IGMP snooping: Yes
Supported security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3
SSH/SSL support: Yes
Loop Protection: Yes
BPDU filtering/protection: Yes
IP-MAC port binding: Yes
Authentication type: RADIUS, TACACS+
design
Product color: Grey
Housing material: Aluminum
LED indicators: Activity, Link, PoE, Power, System
Vandal-proof: No
Suitable for outdoor use: No
Services
Telnet: Yes
Fanless: Yes
Mean time between failures (MTBF): 100,000 h
energy
Power source: DC/PoE
DC input voltage: 48 - 57 V
Power consumption (max.): 200 W
Pressure increase protection: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) power consumption: 185 W
Operating conditions
Operating temperature: -40 - 75 °C
Storage temperature range: -40 - 80 °C
Relative humidity during operation: 5 - 95%
Storage humidity: 0 - 95%
Weight and dimensions
Width: 109 mm
Depth: 145 mm
Height: 62 mm
Packaging data
Packaging width: 190 mm
Packaging depth: 234 mm
Packaging height: 86 mm
Packaging volume: 3823.56 cm³
Package weight: 1.48 kg
Logistics data
UK customs tariff code: 85176200
Country of origin: China
Switch type: Managed
Switch level: L2
Quality of Service (QoS) Support: Yes
Web-based management: Yes
ARP inspection: Yes
System event log: Yes
Connections and interfaces
Number of basic switching RJ-45 Ethernet ports: 8
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of combo SPF connectors: 4
Console port: RJ-45
network
Network standard: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support: No
Copper Ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
Supported cable types: Cat3, Cat4, Cat5, Cat5e
Port mirroring: Yes
Full duplex: Yes
Half-duplex: Yes
Data flow control support: Yes
Broadcast storm control: Yes
Spannbaum protocol: Yes
Self-learning of MAC addresses supported: Yes
VLAN support: Yes
Virtual LAN functions: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
optical fibers
Transmission distance (max): 0.1 km
Data transmission
Routing/switching capacity: 24 Gbit/s
Transfer rate: 17.86 MPPS
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo Frames Support: Yes
Jumbo frames: 9216
Data packet buffer: 4.1 MB
Security
DHCP functions: DHCP relay, DHCP snooping
Access Control List: Yes
IGMP snooping: Yes
Supported security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3
SSH/SSL support: Yes
Loop Protection: Yes
BPDU filtering/protection: Yes
IP-MAC port binding: Yes
Authentication type: RADIUS, TACACS+
design
Product color: Grey
Housing material: Aluminum
LED indicators: Activity, Link, PoE, Power, System
Vandal-proof: No
Suitable for outdoor use: No
Services
Telnet: Yes
Fanless: Yes
Mean time between failures (MTBF): 100,000 h
energy
Power source: DC/PoE
DC input voltage: 48 - 57 V
Power consumption (max.): 200 W
Pressure increase protection: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) power consumption: 185 W
Operating conditions
Operating temperature: -40 - 75 °C
Storage temperature range: -40 - 80 °C
Relative humidity during operation: 5 - 95%
Storage humidity: 0 - 95%
Weight and dimensions
Width: 109 mm
Depth: 145 mm
Height: 62 mm
Packaging data
Packaging width: 190 mm
Packaging depth: 234 mm
Packaging height: 86 mm
Packaging volume: 3823.56 cm³
Package weight: 1.48 kg
Logistics data
UK customs tariff code: 85176200
Country of origin: China
