Datalogic Gryphon I GD4500, portable barcode reader, 1D/2D, Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET,..., Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, 1280 x 800 pixels, 0 - 100000 lux Datalogic Gryphon I GD4500. Type: Portable barcode reader, Scanner type: 1D/2D, Linear (1D) barcodes supported: Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET,.... Transmission technology: Wired, Standard interfaces: USB. Product color: Black, International Protection Rating (IP Code): IP52, Protection feature: Shock-resistant. Power source: DC, Input voltage: 5 V, Power consumption: 300 mA. Weight: 161 g, Width: 68 mm, Depth: 109 mm
Podijelite:
The Gryphon 4500 series impresses with a modern, elegant design and user-friendly ergonomics. Thanks to an innovative 2D imager that operates with warm white light, they capture both 1D and 2D codes quickly and reliably.
To read smaller, short codes, there are HD models with high resolution and for capturing digital watermark codes, there are versions with red light optics.
Equipped with Datalogic“s Motionix motion sensor technology, the scanner automatically enters handheld mode when picked up. Once returned to the cradle, it returns to presentation mode. The charging cradle is movable, allowing the scanner to be used as a presentation scanner while charging.
The wireless models are available with Bluetooth technology (GBT model) or narrowband radio based on Datalogic“s STAR Cordless System (GM model).
One of the most important innovations for the Gryphon 4500 is inductive charging technology. This ensures greater reliability while reducing overall costs by eliminating the need for contact maintenance and cleaning. The wireless models can be used 24/7 without interrupting work processes for cleaning and maintenance.
For healthcare applications, the Gryphon 4500 imagers are available with a special disinfectable, antimicrobial housing.
To read smaller, short codes, there are HD models with high resolution and for capturing digital watermark codes, there are versions with red light optics.
Equipped with Datalogic“s Motionix motion sensor technology, the scanner automatically enters handheld mode when picked up. Once returned to the cradle, it returns to presentation mode. The charging cradle is movable, allowing the scanner to be used as a presentation scanner while charging.
The wireless models are available with Bluetooth technology (GBT model) or narrowband radio based on Datalogic“s STAR Cordless System (GM model).
One of the most important innovations for the Gryphon 4500 is inductive charging technology. This ensures greater reliability while reducing overall costs by eliminating the need for contact maintenance and cleaning. The wireless models can be used 24/7 without interrupting work processes for cleaning and maintenance.
For healthcare applications, the Gryphon 4500 imagers are available with a special disinfectable, antimicrobial housing.
Scanning
Type: Portable barcode reader
Scanner type: 1D/2D
Linear (1D) barcodes supported: Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET, UPC
2D (Matrix & Stacked) Barcodes supported: Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Optical sensor resolution (W x H): 1280 x 800 pixels
Light levels (direct sunlight): 0 - 100000 Lux
Wavelength: 650 nm
Tilt reading angle: 0 - 360°
Slope reading angle: -65 - 65°
Yaw reading angle: -65 - 65°
Movement tolerance (cm/s): 88.9
Connections and interfaces
Transmission technology: Wired
Standard interfaces: USB
Services
International protection class (IP code): IP52
Protective function: shock-resistant
Supported image formats: BMP, JPEG
Product color: Black
Certification: IEC 60825 Class 2
energy
Energy source: direct current
Input voltage: 5 V
Power consumption: 300 mA
Weight and dimensions
Width: 68 mm
Depth: 109 mm
Height: 166 mm
Weight: 161 g
Packaging data
Cables included: USB
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 0 - 95%
Technical details
Certificates of Conformity: RoHS
Logistics data
Tariff number (HS): 84716070
Type: Portable barcode reader
Scanner type: 1D/2D
Linear (1D) barcodes supported: Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, PDF417, Planet, POSTNET, UPC
2D (Matrix & Stacked) Barcodes supported: Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code
Optical sensor resolution (W x H): 1280 x 800 pixels
Light levels (direct sunlight): 0 - 100000 Lux
Wavelength: 650 nm
Tilt reading angle: 0 - 360°
Slope reading angle: -65 - 65°
Yaw reading angle: -65 - 65°
Movement tolerance (cm/s): 88.9
Connections and interfaces
Transmission technology: Wired
Standard interfaces: USB
Services
International protection class (IP code): IP52
Protective function: shock-resistant
Supported image formats: BMP, JPEG
Product color: Black
Certification: IEC 60825 Class 2
energy
Energy source: direct current
Input voltage: 5 V
Power consumption: 300 mA
Weight and dimensions
Width: 68 mm
Depth: 109 mm
Height: 166 mm
Weight: 161 g
Packaging data
Cables included: USB
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 0 - 95%
Technical details
Certificates of Conformity: RoHS
Logistics data
Tariff number (HS): 84716070
