• Power: 1000 Watt, Excellent efficiency 80+ Platinum (up to 94%) • Virtually inaudible SilentWings 135mm fan • Modular cable management for maximum comfort • Full support for GPUs and GPUs with PCIe 6+2 connectors • High-performance 12V lines
Performance
Total power: 1000W
AC Input Voltage: 100-240V
Peak Power: 1070W
AC input frequency: 50 - 63 Hz
Input Current: 13/6.5A
Power factor: 0.99
Combined power (+3.3V): 150 W
Combined Power (+12V): 999.6 W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 83.3 A
Max output current (+5V): 25 A
Max. output current (-12V): 0.5A
Max. output current (+5Vsb): 3A
Hold time: 25.3ms
Efficiency: 93.9%
Energy Protection Features: Overcurrent, Overload, Overvoltage, Overheat, Undervoltage
connections and interfaces
Motherboard connector: 20+4 pin ATX
Number of Molex connectors 4pin: 1
Motherboard power cable length: 60 cm
Number of SATA power connectors: 9
Number of PATA power connections: 2
EPS Power Connector (8-pin): Yes
EPS Power Connector (4+4 pin): Yes
Number of PCI Express power connectors 6+2pin: 4
Floppy Drive Connector: No
Cable Type: Modular
Services
Purpose: personal computer
Power supply unit (PSU) form factor: ATX
80 Plus Certification: 80 PLUS Platinum
Supported motherboard form factors: ATX, micro ATX, Mini-ATX
ATX Version: 3.0
EPS version: 2.92
Noise level: 28.9 dB
Bearing Type: FDB
Mean time between failures (MTBF): 100000 h
design
Color of product: Black
Cooling: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan
Fan speed: 2100 - 2100 RPM
Fan Placement: Top
Built-in display: no
On/off switch: Yes
operating conditions
Operating temperature: 0 - 40 °C
weight and dimensions
Width: 160mm
Depth: 150mm
Height: 86mm
Weight: 1.85kg
packaging data
Packing width: 328 mm
Packing depth: 248 mm
Packing height: 102 mm
Package weight: 3.56 kg
Packing type: box
Technical details
Sustainability Compliance: Yes
Sustainability certificates: CE, Federal Communications Commission (FCC), RoHS, UKCA, WEEE
Warranty period: 10 year(s)
