Barebone ShuttleBarebone NC40U5 Black (Core i5-1235U) 24/7, Dual Video, Ultra HD

processor
Processor manufacturer: Intel
Processor family: Intel® Core™ i5
Processor generation: 12th Generation Intel® Core™ i5 processors
Processor: i5-1235U
Number of processor cores: 10
Processor threads: 12
Performance cores: 2
Efficient cores: 8
Feature: Built-in processor
Processor cache: 12 MB
CPU configuration (max): 1
memory
Memory type: SO-DIMM
Number of memory slots: 2
Maximum RAM memory: 64 GB
Supported memory speed: 3200 MHz
Supported memory: DDR4-SDRAM
Memory channels: Two-channel
Storage voltage: 1.2 V
Feature: Without ECC
Storage medium
Supported storage drives: HDD & SSD
Supported storage drive sizes: 2.5, M.2
Storage drive interface: PCI Express, Serial ATA III
Feature: NVMe
Number of supported storage drives: 3
graphic
Feature: Built-in graphics adapter
Graphics card family: Intel
Built-in graphics card model: Intel® UHD Graphics
Maximum resolution: 7680 x 4320 pixels
network
Feature: Ethernet/LAN
LAN Controller: Intel® I219
Connections and interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-A ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-A ports: 2
Number of HDMI ports: 1
HDMI version: 2.0b
Number of DisplayPort connections: 1
DisplayPort version: 1.4a
Feature: Microphone input
Headphone outputs: 1
Number of Ethernet LAN ports (RJ-45): 1
Feature: Direct current connection (DC)
Expansion slots
PCI Express Slots Version: 3.0, 4.0
Number of M.2 (M) slots: 2
design
Case type: 0.84L sized PC
Product color: Black
Cooling: Active
Feature: On/Off switch
LED indicators: HDD, power
Housing material: plastic
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: VESA mount
Panel mounting interface: 75 x 75,100 x 100 mm
Product type: Mini PC Barebone
Safety: CB IEC60950/62368, cTUVus (UL 62368)
Services
Motherboard Chipset: Intel SoC
Number of supported processors: 1
BIOS type: AMI
Feature: Trusted Platform Module (TPM)
Trusted Platform Module (TPM) Version: 2.0
Technical details
Conformity certificates: BSMI, CE, Federal Communications Commission (FCC), RoHS, UKCA
Logistics data
Tariff number (HS): 84733080
software
Supports Windows operating systems: Windows 10, Windows 11
Feature: Supported Linux operating systems
sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR, ErP
energy
Power supply type: External AC adapter
Power supply: 65 W
Number of power supply units: 1
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power supply output voltage: 19 V
AC adapter output current: 3.42 A
Operating conditions
Operating temperature: 0 - 40 °C
Relative humidity during operation: 10 - 90%
Weight and dimensions
Width: 142 mm
Depth: 142 mm
Height: 42 mm
Weight: 400 g
Package weight: 1.2 kg
Scope of delivery
Feature: Power cable included
Feature: AC power adapter
Feature: Quick Start Overview
Feature: Driver included
