Axis Q1971-E, IP Security Camera, Indoor & Outdoor, Wired, Wall Mounted, Black, White, Cartridge (Form). Type: IP Security Camera, Supported Positioning: Indoor & Outdoor, Transmission Technology: Wired. Mounting Type: Wall Mounted, Product Color: Black, White, Form Factor: Cartridge (Form). Viewing Angle (Horizontal): 15°, Viewing Angle (Vertical): 11°, Camera Pixel Size: 17 µm. Sensor Type: Microbolometer, Effective Sensor Resolution (Thermal Module): 384 x 288 pixels. Lens Diameter: 2.5 cm, Minimum Focusing Distance: 18.2 m
Podijelite:
Services
Type: IP security camera
Supported positioning: Indoor & Outdoor
Transmission technology: Wired
Heating module: Yes
design
Form factor: Cartridge (shape)
Mounting type: Wall
Product color: Black, White
Housing material: Aluminum, polycarbonate (PC)
International protection rating (IP code): IP66, IP67
IK Code: IK10
camera
Viewing angle (horizontal): 15°
Viewing angle (vertical): 11°
Camera pixel size: 17 µm
Image sensor
Number of sensors: 1
Effective sensor resolution (thermal module): 384 x 288 pixels
Sensor type: Microbolometer
lens
Number of lenses: 1
Lens diameter: 2.5 cm
Maximum aperture: 1
Close focusing distance: 18.2 m
video
Maximum resolution: 768 x 576 pixels
Supported video formats: AVC, H.264, H.265, HEVC, M-JPEG
Up to 30 frames per second: 30 fps
Video streaming: Yes
Gain control type: Auto
Image quality adjustment: brightness, contrast, sharpness
Flip & Mirror: Yes
Text overlay: Yes
Image stabilizer: Yes
Bitrate control: Variable bitrate (VBR)
Audio
Audio system: 2-way
Audio system - full duplex: Yes
Supported audio formats: AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
Audio detection: Yes
network
Ethernet/LAN: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Network standard: IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Streaming method: Multicasting
Storage medium
Integrated card reader: Yes
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory: 8192 MB
RAM capacity: 2048 MB
Connections and interfaces
Number of Ethernet LAN ports (RJ-45): 1
Microphone input: Yes
Terminal block connection: Yes
Direct current (DC) connection: Yes
Security
Password protection: Yes
Video motion detector: Yes
Active counterfeit alert: Yes
Supported security algorithms: EAP-TLS, HTTPS, MSCHAPv2
Warning notification type: Email
Data protection: Yes
Pixel counter: Yes
Digest authentication: Yes
Management functions
Cloud-managed: Yes
energy
Power source: Direct current, PoE
Power consumption (standard operation): 3.6 W
Power consumption (max.): 12.95 W
Power consumption (Power over Ethernet (PoE)): 12.95 W
Operating conditions
Operating temperature: -40 - 60 °C
Storage temperature range: -40 - 65 °C
Relative humidity during operation: 10 - 100%
Storage humidity: 5 - 95%
Weight and dimensions
Width: 132 mm
Depth: 272 mm
Height: 132 mm
Weight: 1.4 kg
Scope of delivery
Number of cameras: 1
Other functions
Does not contain: CFR, halogen, PVC/BFR
Type: IP security camera
Supported positioning: Indoor & Outdoor
Transmission technology: Wired
Heating module: Yes
design
Form factor: Cartridge (shape)
Mounting type: Wall
Product color: Black, White
Housing material: Aluminum, polycarbonate (PC)
International protection rating (IP code): IP66, IP67
IK Code: IK10
camera
Viewing angle (horizontal): 15°
Viewing angle (vertical): 11°
Camera pixel size: 17 µm
Image sensor
Number of sensors: 1
Effective sensor resolution (thermal module): 384 x 288 pixels
Sensor type: Microbolometer
lens
Number of lenses: 1
Lens diameter: 2.5 cm
Maximum aperture: 1
Close focusing distance: 18.2 m
video
Maximum resolution: 768 x 576 pixels
Supported video formats: AVC, H.264, H.265, HEVC, M-JPEG
Up to 30 frames per second: 30 fps
Video streaming: Yes
Gain control type: Auto
Image quality adjustment: brightness, contrast, sharpness
Flip & Mirror: Yes
Text overlay: Yes
Image stabilizer: Yes
Bitrate control: Variable bitrate (VBR)
Audio
Audio system: 2-way
Audio system - full duplex: Yes
Supported audio formats: AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS, PCM
Audio detection: Yes
network
Ethernet/LAN: Yes
Ethernet interface type: Fast Ethernet, Gigabit Ethernet
Network standard: IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Streaming method: Multicasting
Storage medium
Integrated card reader: Yes
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Flash memory: 8192 MB
RAM capacity: 2048 MB
Connections and interfaces
Number of Ethernet LAN ports (RJ-45): 1
Microphone input: Yes
Terminal block connection: Yes
Direct current (DC) connection: Yes
Security
Password protection: Yes
Video motion detector: Yes
Active counterfeit alert: Yes
Supported security algorithms: EAP-TLS, HTTPS, MSCHAPv2
Warning notification type: Email
Data protection: Yes
Pixel counter: Yes
Digest authentication: Yes
Management functions
Cloud-managed: Yes
energy
Power source: Direct current, PoE
Power consumption (standard operation): 3.6 W
Power consumption (max.): 12.95 W
Power consumption (Power over Ethernet (PoE)): 12.95 W
Operating conditions
Operating temperature: -40 - 60 °C
Storage temperature range: -40 - 65 °C
Relative humidity during operation: 10 - 100%
Storage humidity: 5 - 95%
Weight and dimensions
Width: 132 mm
Depth: 272 mm
Height: 132 mm
Weight: 1.4 kg
Scope of delivery
Number of cameras: 1
Other functions
Does not contain: CFR, halogen, PVC/BFR
