eGarner webshop - Matične Ploče
• ITX mainboard with socket AMD AM5 for AMD RYZEN 7000 series CPU • AMD X670E chipset, Radeon Vega graphics (Ryzen CPU) graphics • 64 GB max. RAM, DDR5 up to 6400MHz • RGB lighting, ROG FPS-II Card, ROG STRIX HIVE • 1x HDMI, 4x USB 4.0, 8x USB 3.2, 1x USB 3.0, 6x USB 2.0, 2xUSB-C, 1x G
processor
Processor manufacturer: AMD
Processor socket: socket AM5
Storage
Supported memory: DDR5-SDRAM
Number of memory slots: 2
RAM memory maximum: 64 GB
RAM type: DIMM
Memory Channels: Dual Channel
ECC: Yes
Without ECC: Yes
Supported memory speed: 4800,5000,5200,5400,5600,5800,6000,6200,6400MHz
Unbuffered memory: Yes
Storage controller
Supported storage drive interfaces: M.2, SATA III
Supported storage drives: HDD & SSD
Number of storage drives supported: 4
graphic
Maximum resolution: 3840 x 2160 pixels
Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Ports: 1
SATA III ports: 2
Front panel audio plug: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 1
EPS power connector (8-pin): Yes
Rear I/O ports
Number of USB 2.0 ports: 3
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 5
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
Number of USB4 Gen 3×2 ports: 2
network
WiFi: Yes
Built-in Ethernet port: Yes
Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
LAN controller: Intel I225-V
Top WLAN standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Bluetooth version: 5.2
characteristics
Component for: PC
Motherboard form factor: mini ITX
Motherboard chipset family: AMD
Motherboard chipset: AMD X670
Audio chip: Realtek ALC4050H
Supports Windows operating systems: Windows 10 x64, Windows 11 x64
Expansion slots
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 2
BIOS
BIOS Type: UEFI AMI
BIOS memory size: 256 Mbit
Weight and dimensions
Width: 170mm
Depth: 170mm
Other functions
Weight: 870g
Processor manufacturer: AMD
Processor socket: socket AM5
Storage
Supported memory: DDR5-SDRAM
Number of memory slots: 2
RAM memory maximum: 64 GB
RAM type: DIMM
Memory Channels: Dual Channel
ECC: Yes
Without ECC: Yes
Supported memory speed: 4800,5000,5200,5400,5600,5800,6000,6200,6400MHz
Unbuffered memory: Yes
Storage controller
Supported storage drive interfaces: M.2, SATA III
Supported storage drives: HDD & SSD
Number of storage drives supported: 4
graphic
Maximum resolution: 3840 x 2160 pixels
Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Ports: 1
SATA III ports: 2
Front panel audio plug: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 1
EPS power connector (8-pin): Yes
Rear I/O ports
Number of USB 2.0 ports: 3
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 5
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
Number of USB4 Gen 3×2 ports: 2
network
WiFi: Yes
Built-in Ethernet port: Yes
Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
LAN controller: Intel I225-V
Top WLAN standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Bluetooth version: 5.2
characteristics
Component for: PC
Motherboard form factor: mini ITX
Motherboard chipset family: AMD
Motherboard chipset: AMD X670
Audio chip: Realtek ALC4050H
Supports Windows operating systems: Windows 10 x64, Windows 11 x64
Expansion slots
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 2
BIOS
BIOS Type: UEFI AMI
BIOS memory size: 256 Mbit
Weight and dimensions
Width: 170mm
Depth: 170mm
Other functions
Weight: 870g
