Chipset: Intel® B860 / Processor socket: Socket 1851 / Memory support: 4x DDR5 / Form factor: Micro-ATX
| Series - Motherboards | ||
| series | Asus ROG STRIX series | |
| Mainboard basic features | ||
| Manufacturer | ASUS | |
| Chipset | Intel® B860 | |
| Form factor | Micro-ATX | |
| Motherboard processor | ||
| Processor family | Intel | |
| Processor socket | Base 1851 | |
| Supported processors | Core Ultra 200 | |
| Motherboard memory | ||
| Number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| Memory type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| supported memory clock | up to 9066 MHz | |
| Motherboard expansion slots | ||
| PCI Express x16 (total) | 1x | |
| PCI Express 5.0 x16 | 1x | |
| M.2 | 4x | |
| Mainboard external connections | ||
| DisplayPort | Yes | |
| HDMI | Yes | |
| USB 4.0 | 1x | |
| USB 3.2 Type-C | 1x | |
| USB 3.1 Type-A | 1x | |
| USB 3.0 | 3x | |
| USB 2.0 | 4x | |
| Ethernet (LAN) | 1 x | |
| Thunderbolt | 1x | |
| 3.5mm jack | 2x | |
| Toslink/S/PDIF (optical) | Yes | |
| Motherboard internal connections | ||
| SATA 6 GB/s | 4x | |
| USB 3.1 header | 1x (Type-C) | |
| USB 3.0 header | 1 x | |
| USB 2.0 header | 2 x | |
| RAID | 0/1/5/10 | |
| Power connections | 1x 24-pin ATX, 2x 8-pin EPS12V | |
| Audio channels | 7.1 | |
| Audio codec | Realtek ALC1220P | |
| Audio features | AMP (Savitech SV3H712), ASUS SupremeFX | |
| Motherboard cooling | ||
| CPU fan 4-pin | 2x | |
| 4-pin case fan | 4x | |
| Pump 4-pin | 1x | |
| Thermal sensor | 1x | |
| Motherboard lighting | ||
| ARGB header 3-pin | 3x | |
| Mainboard network | ||
| LAN controller | RJ-45 LAN (2.5GBase-T, Intel) | |
| Transfer rate | 10/100/1000/2500 Mbps | |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) | |
| Bluetooth | 5.4 | |
| Mainboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 4x | |
| Diagnostic LED | Yes | |
| Integrated IO panel | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
