Chipset: Intel® B760 / Processor socket: Socket 1700 / Memory support: 4x DDR5 / Form factor: ATX
| Mainboard basic properties | ||
| Manufacturer | ASUS | |
| Chipset | Intel® B760 | |
| Form factor | ATX | |
| BIOS type | 256Mb Flash ROM, UEFI AMI BIOS | |
| Dimensions | (ATX) 305mm × 244mm | |
| Motherboard processor | ||
| processor family | Intel | |
| processor socket | Base 1700 | |
| Supported processors | 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold & Celeron® | |
| Motherboard memory | ||
| Number of DIMM slots | 4x | |
| DIMM format | 288-pin DIMM | |
| Maximum main memory | 128GB | |
| Storage type | DDR5 | |
| Non-ECC, Unbuffered | Yes | |
| supported memory clock | 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 | |
| Motherboard expansion slots | ||
| PCI Express x16 (total) | 2x | |
| PCI Express 5.0 x16 | 1x | |
| PCI Express 3.0 x16 | 1x | |
| PCI Express x1 | 2x (3.0) | |
| M.2 | 3x | |
| Mainboard external connections | ||
| DisplayPort | Yes | |
| HDMI | Yes | |
| USB 3.2 | 2x (1x Type-C, 1x Type-A) | |
| USB 3.1 Type-A | 6x | |
| Ethernet (LAN) | 1x | |
| 3.5mm jack | 5x | |
| Toslink/S/PDIF (optical) | Yes | |
| Mainboard internal connections | ||
| SATA 6GB/s | 4x | |
| USB 3.2 headers | 1x | |
| USB 3.1 headers | 1x (Gen1) | |
| USB 2.0 headers | 2x | |
| Thunderbolt 4 | Yes | |
| TPM header | Yes | |
| Chassis intrusion header | Yes | |
| RAID | 0/1/5/10 | |
| Power connections | 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V | |
| Audio channels | 7.1 | |
| Audio codec | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 2x | |
| 4-pin case fan | 4x | |
| Pump 4-pin | 1x | |
| Motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB header 3-pin | 3x | |
| lighting color | RGB | |
| LED compatibility | ASUS Aura Sync | |
| Motherboard network | ||
| Transfer rate | 10/100/1000/2500 Mb/s | |
| WIRELESS INTERNET ACCESS | 802.11a/b/g/n/ac/ax | |
| Bluetooth | 5.2 | |
| Mainboard special features | ||
| M.2 passive cooler | Yes | |
| Diagnostic LED | Yes | |
| Integrated IO cover | Yes | |
| Back plate | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
