ASUS PRIME Z790M-PLUS mATX Gaming Motherboard Socket 1700 DP/HDMI/M.2/USB-C

processor
Processor manufacturer: Intel
Processor socket: LGA 1700
Compatible processors: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold

Storage
Supported memory: DDR5-SDRAM
Number of memory slots: 4
RAM memory maximum: 128 GB
RAM type: DIMM
Memory Channels: Dual Channel
Without ECC: Yes
Supported memory speed: 4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200MHz
Unbuffered memory: Yes

Storage controller
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA
Supported storage drives: HDD & SSD
Maximum number of HDD supported: 3
Number of storage drives supported: 4
RAID support: Yes
RAID levels: 0, 1, 5, 10

Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 2
SATA ports: 4
S/PDIF out connector: Yes
Audio connection: Yes
ATX power connector (24-pin): Yes
Power Fan Connector: Yes
CPU fan connector: Yes
Number of chassis fan connectors: 3
Number of Molex connectors 4pin: 1
EPS power connector (8-pin): Yes
Number of COM connectors: 1
Serial port headers: 1
Thunderbolt headers: 1
12V power connection: Yes
RGB LED header: Yes

Rear I/O ports
Number of USB 2.0 ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type-C ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 1
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
USB 3.2 Gen 2x2 Type-C Number of ports: 1
HDMI version: 2.0
Number of DisplayPort connections: 1
DisplayPorts version: 1.4
Headphone outputs: 1
Line in: Yes
Microphone input: Yes
Number of COM ports: 1
USB connector: USB Type-A

network
WiFi: No
Built-in Ethernet port: Yes
Ethernet interface type: Gigabit Ethernet

characteristics
Component for: PC
Motherboard form factor: micro ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel Z790
Audio Channels: 7.1 channels
Power source: ATX
Supports Windows operating systems: Windows 10, Windows 11

Expansion slots
PCI Express x1 slots (Gen 4.x): 2
PCI Express x16 slots (Gen 4.x): 1
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 3

BIOS
BIOS Type: UEFI AMI
BIOS memory size: 192 Mbit

Weight and dimensions
Width: 244mm
Depth: 244mm

scope of delivery
Cables included: SATA
Included Software: ASUS Exclusive Software
Armory Crate
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
AI Suite 3
- TurboV EVO
- DIGI+ VRM
- PC Cleaner
ASUS CPU-Z
Norton 360 Deluxe (60 Days Free Trial)
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
