• ATX mainboard with Intel 1700 socket for Intel Core 13th generation CPU • Intel B760 chipset, Intel HD Graphics • 128 GB max. RAM, DDR4 up to 5066MHz • 1x DisplayPort, 1x HDMI, 4x USB 3.2, 2x USB 2.0, 1xUSB-C, 1x 2.5 Gigab • Supports: Windows® 11, Windows® 10 64-bit
processor
Processor manufacturer: Intel
Processor socket: LGA 1700
Compatible processors: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Maximum number of SMP processors: 1
Supported processor slots: LGA 1700
Storage
Supported memory: DDR4-SDRAM
Number of memory slots: 4
RAM memory maximum: 128 GB
RAM type: DIMM
Memory Channels: Dual Channel
Without ECC: Yes
Supported memory speed: 5066,5000,4800,4600,4400,4266,4000,3733,3600,3466,3400,3333,3200,3000,2933,2800,2666,2400,2133MHz
Supported memory clock speed (max): 5066 MHz
Unbuffered memory: Yes
Storage controller
Supported storage drive interfaces: M.2, SATA III
Supported storage drives: HDD & SSD
Maximum number of HDD supported: 4
Number of storage drives supported: 7
RAID support: Yes
RAID levels: 0, 1, 5, 10
graphic
Parallel processing technology: Not supported
Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 2
SATA III ports: 4
S/PDIF out connector: Yes
Front panel audio plug: Yes
Front panel connector: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 3
Number of Molex connectors 4pin: 1
EPS power connector (8-pin): Yes
Number of COM connectors: 1
TPM connector: Yes
Thunderbolt headers: 1
12V power connection: Yes
RGB LED header: Yes
Rear I/O ports
Number of USB 2.0 ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 2
Number of Ethernet LAN ports (RJ-45): 1
Number of VGA (D-Sub) ports: 1
Number of HDMI ports: 1
USB 3.2 Gen 2x2 Type-C Number of ports: 1
HDMI version: 2.1
Number of DisplayPort connections: 1
DisplayPorts version: 1.4
Headphone outputs: 1
Line in: Yes
network
WiFi: No
Built-in Ethernet port: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
characteristics
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel B760
Audio Channels: 7.1 channels
Cooling: Passive
Power source: ATX
Supports Windows operating systems: Windows 10, Windows 11
Expansion slots
PCI Express x1 (Gen 3.x) ports: 2
PCI Express x16 slots (Gen 4.x): 1
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 3
BIOS
BIOS Type: UEFI AMI
BIOS memory size: 128 Mbit
Weight and dimensions
Width: 305mm
Depth: 244mm
scope of delivery
Cables included: SATA
User manual: Yes
Other functions
Number of M.2 (E) slots: 1
Processor manufacturer: Intel
Processor socket: LGA 1700
Compatible processors: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Maximum number of SMP processors: 1
Supported processor slots: LGA 1700
Storage
Supported memory: DDR4-SDRAM
Number of memory slots: 4
RAM memory maximum: 128 GB
RAM type: DIMM
Memory Channels: Dual Channel
Without ECC: Yes
Supported memory speed: 5066,5000,4800,4600,4400,4266,4000,3733,3600,3466,3400,3333,3200,3000,2933,2800,2666,2400,2133MHz
Supported memory clock speed (max): 5066 MHz
Unbuffered memory: Yes
Storage controller
Supported storage drive interfaces: M.2, SATA III
Supported storage drives: HDD & SSD
Maximum number of HDD supported: 4
Number of storage drives supported: 7
RAID support: Yes
RAID levels: 0, 1, 5, 10
graphic
Parallel processing technology: Not supported
Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 2
SATA III ports: 4
S/PDIF out connector: Yes
Front panel audio plug: Yes
Front panel connector: Yes
ATX power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 3
Number of Molex connectors 4pin: 1
EPS power connector (8-pin): Yes
Number of COM connectors: 1
TPM connector: Yes
Thunderbolt headers: 1
12V power connection: Yes
RGB LED header: Yes
Rear I/O ports
Number of USB 2.0 ports: 2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 2
Number of Ethernet LAN ports (RJ-45): 1
Number of VGA (D-Sub) ports: 1
Number of HDMI ports: 1
USB 3.2 Gen 2x2 Type-C Number of ports: 1
HDMI version: 2.1
Number of DisplayPort connections: 1
DisplayPorts version: 1.4
Headphone outputs: 1
Line in: Yes
network
WiFi: No
Built-in Ethernet port: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
characteristics
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: Intel
Motherboard chipset: Intel B760
Audio Channels: 7.1 channels
Cooling: Passive
Power source: ATX
Supports Windows operating systems: Windows 10, Windows 11
Expansion slots
PCI Express x1 (Gen 3.x) ports: 2
PCI Express x16 slots (Gen 4.x): 1
PCI Express x16 slots (Gen 5.x): 1
Number of M.2 (M) slots: 3
BIOS
BIOS Type: UEFI AMI
BIOS memory size: 128 Mbit
Weight and dimensions
Width: 305mm
Depth: 244mm
scope of delivery
Cables included: SATA
User manual: Yes
Other functions
Number of M.2 (E) slots: 1
