Chipset: Intel® Z890 / Processor socket: Socket 1851 / Memory support: 4x DDR5 / Form factor: ATX
| series - motherboards | ||
| series | AsRock STEEL LEGEND series | |
| motherboard basic properties | ||
| Manufacturer | ASUS | |
| chipset | Intel® Z890 | |
| form factor | ATX | |
| motherboard processor | ||
| processor family | Intel | |
| processor socket | base 1851 | |
| Supported processors | Core Ultra 200 | |
| motherboard memory | ||
| number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| storage type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| supported memory clock | up to 9066 MHz | |
| motherboard expansion slots | ||
| PCI-Express x16 (total) | 2x | |
| PCI-Express 5.0 x16 | 1x | |
| PCI-Express 4.0 x16 | 1x | |
| PCI-Express x4 | 1x | |
| M.2 | 4x | |
| motherboard external connections | ||
| HDMI | Yes | |
| USB 4.0 | 2x | |
| USB 3.1 Type-A | 2x | |
| USB 3.0 | 4x | |
| USB 2.0 | 2x | |
| Ethernet (LAN) | 1 x | |
| Thunderbolt | 2x | |
| 3.5mm jack | 2x | |
| motherboard internal connections | ||
| SATA 6 GB/s | 4x | |
| USB 3.2 header | 1x | |
| USB 3.0 header | 2 x | |
| USB 2.0 header | 2 x | |
| TPM header | Yes | |
| RAID | 0/1/5/10 | |
| power connections | 1x 24-pin ATX, 2x 8-pin EPS12V | |
| audio channels | 7.1 | |
| audio codec | Realtek ALC1220 | |
| motherboard cooling | ||
| CPU fan 4-pin | 2x | |
| case fan 4-pin | 5x | |
| pump 4-pin | 1x | |
| thermal sensor | 1x | |
| motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB header 3-pin | 3x | |
| lighting color | RGB | |
| motherboard network | ||
| LAN controller | 1x RJ-45 2.5Gb LAN (Realtek RTL8125BG) | |
| transfer rate | 10/100/1000/2500 Mb/s | |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) | |
| Bluetooth | 5.4 | |
| motherboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 3x | |
| Diagnostic LED | Yes | |
| IO panel integrated | Yes | |
| Audio+solid capacitors | Yes | |
| Condition | ||
| item condition | New | |
