eGarner webshop - Matične Ploče
Chipset: AMD X870 / Processor socket: Socket AM5 / Memory support: 4x DDR5 / Form factor: ATX
| Series - Mainboards | ||
| series | AsRock PHANTOM Series | |
| Basic motherboard characteristics | ||
| Chipset manufacturer | AMD | |
| Manufacturer | ASRock | |
| Chipset | AMD X870 | |
| Form factor | ATX | |
| BIOS type | 256Mb AMI UEFI Legal BIOS with GUI support | |
| Dimensions | (ATX) 305 mm × 224 mm | |
| Motherboard processor | ||
| Processor family | AMD | |
| processor socket | Socket AM5 | |
| Supported processors | Ryzen 7000, Ryzen 8000G, Ryzen 9000 | |
| Motherboard memory | ||
| Number of DIMM slots | 4x | |
| Maximum main memory | 256 GB | |
| Storage type | DDR5 | |
| Non-ECC, Un-buffered | Yes | |
| supported memory clock | up to 8400 MHz | |
| Motherboard expansion slots | ||
| PCI-Express x16 (total) | 2x | |
| PCI-Express 5.0 x16 | 1x | |
| PCI-Express 4.0 x16 | 1x | |
| M.2 | 5x | |
| Motherboard External Connectors | ||
| HDMI | 1x | |
| USB 4.0 | 2x (with DisplayPort 1.4a) | |
| USB 3.1 Type-A | 2x | |
| USB 3.0 | 3x | |
| USB 2.0 | 4x | |
| Ethernet (LAN) | 1 x | |
| 3.5mm jack | 2x | |
| Toslink/S/PDIF (optical) | Yes | |
| Internal motherboard connectors | ||
| SATA 6 GB/s | 2x | |
| USB 3.2 Header | 1x | |
| USB 3.0 Header | 2 x | |
| USB 2.0 Header | 2 x | |
| RAID | 0/1/10 | |
| Power connections | 1x 24-pin ATX, 2x 8-pin EPS12V | |
| Audio channels | 7.1 | |
| Audio codec | Realtek ALC4082 | |
| Motherboard cooling | ||
| CPU fan 4-pin | 2x | |
| 4-pin case fan | 3x | |
| 4-pin pump | 2x | |
| Thermal sensor | 1x | |
| Motherboard lighting | ||
| RGB header 4-pin | 1x | |
| ARGB 3-pin header | 3x | |
| Lighting color | RGB | |
| Motherboard network | ||
| LAN Controller | 1x RJ-45 (5GBase-T, Realtek RTL8126) | |
| Transfer rate | 10/100/1000/2500/5000 Mb/s | |
| Wi-Fi | Wi-Fi 7 (WLAN 802.11a/b/g/n/ac/ax/be, 2x2) | |
| Bluetooth | 5.4 | |
| Motherboard features | ||
| USB BIOS Flashback | Yes | |
| M.2 passive cooler | 5x | |
| Diagnostic LED | Yes | |
| Integrated I/O shield | Yes | |
| Backplate | Yes | |
| Audio + solid capacitors | Yes | |
| Condition | ||
| Item condition | New | |
