APC Back-UPS 500, 230V, Battery 12V, 7.0Ah, Standby (Offline), 0.5 kVA, 300 W, Sine, 160V, 300V APC Back-UPS 500, 230V, Battery 12V, 7.0Ah. UPS topology: Standby (Offline), Output capacity: 0.5 kVA, Output power: 300 W. AC plug types: C13 coupler, Plug: C14 coupler, Number of AC outlets: 4 AC outlets. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 Ah, Battery capacity: 83 VAh. Form factor: Tower, Product color: Beige, Cable length: 1.83 m. Conformity certificates: RoHS, Certifications: C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE, REACH
Podijelite:
This product, part of the Back-UPS series, features a total of six outlets, three of which function as UPS battery backup and three as surge-only outlets. Its runtime at 100 W is 24 minutes and 20 seconds. It provides data line protection with an analog RJ45 telephone line for telephone, fax, modem, or DSL. It measures 16.5 x 9.1 x 28.4 cm and weighs 6.32 kg. The BK550EI ensures that office systems and their valuable data are protected from dangerous power surges, spikes, and power outages.
Features
UPS topology: Standby (Offline)
Output capacity: 0.5 kVA
Output power: 300 W
Waveform: Sine
Input operating voltage (min): 160 V
Input operating voltage (max): 300 V
Input frequency: 50/60 Hz
Output frequency regulation: 47 - 63 Hz
Increase in energy: 310 J
Hold time (min.): 6 ms
Hold time (max.): 10 ms
Efficiency: 99%
Noise level: 40 dB
Feature: Pressure rise protection
Surge protection functions: Digital Subscriber Line (DSL), fax, modem, telephone
Energy protection features: Overload protection
Feature: Acoustic signals
Acoustic alarm modes: Low battery warning, overload alarm
Connections and interfaces
AC plug types: C13 coupler
Connector: C14 coupler
Number of AC outputs: 4 AC outputs
Number of Output IEC Jumpers: 2
Feature: USB port
Battery
Battery technology: Sealed lead acid (VRLA)
Battery capacity: 7 Ah
Battery capacity: 83 VAh
Battery voltage: 12 V
Typical backup time at full load: 3.8 min
Typical backup time at half load: 13.8 min
Battery life (max.): 6 year(s)
Battery charging time: 8 h
Feature: Automatic battery test
design
Form factor: Tower
Cable length: 1.83 m
Product color: Beige
LED indicators: battery replacement
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -15 - 45 °C
Relative humidity during operation: 0 - 95%
Storage humidity: 0 - 95%
Operating altitude: 0 - 3000 m
Storage altitude: 0 - 15000 m
Certificates
Certificates of Conformity: RoHS
Certification: C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE, REACH
Scope of delivery
Included cables: Telephone (RJ-11), USB cable
Feature: Quick Installation Guide
sustainability
Sustainability certificates: ENERGY STAR, Green Premium
Weight and dimensions
Width: 91 mm
Depth: 284 mm
Height: 165 mm
Weight: 6.32 kg
Packaging data
Feature: Warranty Card
Feature: Software CD
Included software: PowerChute Personal Edition
Packaging width: 241 mm
Packaging depth: 368 mm
Packaging height: 178 mm
Package weight: 7.05 kg
Logistics data
Products per pallet: 48 pieces
Tariff number (HS): 85078000
Number of products per shipping carton: 1 piece(s)
Other functions
Nominal output voltage: 230 V
Nominal input voltage: 230 V
Property: Filtering
UPS topology: Standby (Offline)
Output capacity: 0.5 kVA
Output power: 300 W
Waveform: Sine
Input operating voltage (min): 160 V
Input operating voltage (max): 300 V
Input frequency: 50/60 Hz
Output frequency regulation: 47 - 63 Hz
Increase in energy: 310 J
Hold time (min.): 6 ms
Hold time (max.): 10 ms
Efficiency: 99%
Noise level: 40 dB
Feature: Pressure rise protection
Surge protection functions: Digital Subscriber Line (DSL), fax, modem, telephone
Energy protection features: Overload protection
Feature: Acoustic signals
Acoustic alarm modes: Low battery warning, overload alarm
Connections and interfaces
AC plug types: C13 coupler
Connector: C14 coupler
Number of AC outputs: 4 AC outputs
Number of Output IEC Jumpers: 2
Feature: USB port
Battery
Battery technology: Sealed lead acid (VRLA)
Battery capacity: 7 Ah
Battery capacity: 83 VAh
Battery voltage: 12 V
Typical backup time at full load: 3.8 min
Typical backup time at half load: 13.8 min
Battery life (max.): 6 year(s)
Battery charging time: 8 h
Feature: Automatic battery test
design
Form factor: Tower
Cable length: 1.83 m
Product color: Beige
LED indicators: battery replacement
Operating conditions
Operating temperature: 0 - 40 °C
Storage temperature range: -15 - 45 °C
Relative humidity during operation: 0 - 95%
Storage humidity: 0 - 95%
Operating altitude: 0 - 3000 m
Storage altitude: 0 - 15000 m
Certificates
Certificates of Conformity: RoHS
Certification: C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE, REACH
Scope of delivery
Included cables: Telephone (RJ-11), USB cable
Feature: Quick Installation Guide
sustainability
Sustainability certificates: ENERGY STAR, Green Premium
Weight and dimensions
Width: 91 mm
Depth: 284 mm
Height: 165 mm
Weight: 6.32 kg
Packaging data
Feature: Warranty Card
Feature: Software CD
Included software: PowerChute Personal Edition
Packaging width: 241 mm
Packaging depth: 368 mm
Packaging height: 178 mm
Package weight: 7.05 kg
Logistics data
Products per pallet: 48 pieces
Tariff number (HS): 85078000
Number of products per shipping carton: 1 piece(s)
Other functions
Nominal output voltage: 230 V
Nominal input voltage: 230 V
Property: Filtering
