AM5 GIGABYTE B650 AORUS ELITE AX V2 DDR5

processor
Processor manufacturer: AMD
Processor socket: Socket AM5
Compatible processors: AMD Ryzen™ 7
Maximum number of SMP processors: 1
Supported processor slots: Socket AM5
Maximum internal memory supported by processor: 192 GB
Storage
Supported memory: DDR5-SDRAM
Number of memory slots: 4
RAM type: DIMM
Memory Channels: Dual Channel
Feature: Without ECC
Supported memory speed: 4400,4800,5200,5600,6000,6200,6400,6600,6666,6800,7000,7200,7600,7800,8000 MHz
RAM memory maximum: 192 GB
Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB
Feature: Unbuffered memory
Storage controller
Supported storage drives: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Maximum number of HDD supported: 4
Number of storage drives supported: 7
Feature: RAID support
RAID levels: 0, 1, 10
graphic
Parallel processing technology: Not supported
Maximum resolution: 7680 x 4320 pixels
Feature: HDCP
DirectX version: 12.0
Feature: Discrete graphics support
Internal I/O ports
Number of USB 2.0 interfaces: 2
USB 3.2 Gen 1 (3.1 Gen 1) Ports: 1
USB 3.2 Gen 2x2 ports: 1
SATA III ports: 4
Total number of SATA ports: 4
Feature: Front panel audio plug
Feature: Front panel connector
Feature: ATX power connector (24-pin)
Number of EATX energy plugs: 2
Feature: CPU fan connector
Feature: EPS power connector (8-pin)
Feature: TPM connector
Feature: 12V power connection
Feature: RGB LED header
Rear I/O ports
Number of USB 2.0 ports: 4
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports: 5
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports: 2
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports: 1
Number of Ethernet LAN ports (RJ-45): 1
Number of HDMI ports: 1
HDMI version: 2.1
Headphone outputs: 1
Feature: Microphone input
Feature: S/PDIF output
Optical audio digital output: 1
WiFi AP antenna socket: 2
USB connector: USB Type-A, USB Type-C
network
Feature: Ethernet/LAN
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Feature: WiFi
Top WLAN standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WiFi controller model: Realtek RTL8852CE
Feature: Bluetooth
Bluetooth version: 5.3
characteristics
Motherboard chipset: AMD B650
Audio chip: Realtek ALC897
Audio Channels: 7.1 channels
Product color: Black
PC health monitoring: fan, noise, temperature, voltage, water cooling
Component for: PC
Motherboard form factor: ATX
Motherboard chipset family: AMD
Supports Windows operating systems: Windows 10 x64, Windows 11 x64
Expansion slots
PCI Express x16 (Gen 3.x) ports: 2
PCI Express x16 slots (Gen 4.x): 1
Number of M.2 (M) slots: 3
BIOS
BIOS Type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 5.0
Feature: Clear CMOS jumper
Feature: Clear CMOS button
Desktop Management Interface (DMI) Version: 2.7
System Management BIOS (SMBIOS) Version: 2.7
Logistics data
Country of origin: China
Quantity per shipping box: 1 piece(s)
Battery/battery
Battery weight: 3g
Lithium weight per battery: 0.07 g
Number of battery cells: 1
Rechargeable battery technology: Lithium Manganese Dioxide (LiMnO2)
Battery/battery type: CR2032
Packaging data
Packaging width: 335 mm
Packaging depth: 270 mm
Packaging height: 80 mm
Package weight: 2.01 kg
Weight and dimensions
Width: 305mm
Depth: 244mm
Height: 35mm
scope of delivery
Cables included: SATA
Feature: Batteries included
Feature: Antenna included
Included software: Norton® Internet Security (OEM version)LAN bandwidth management software
Technical details
Warranty period: 3 year(s)
