Cudy GS2024S2, Managed, L2/L3, Gigabit Ethernet (10/100/1000), Rack Mount, 1U
Cudy GS2024S2. Switch type: Managed, Switch level: L2/L3. Basic Switching RJ-45 Ethernet Ports type: Gigabit Ethernet (10/100/1000), Number of basic switching RJ-45 Ethernet ports: 24, Number of installed SFP modules: 4, console port: RJ-45. MAC address table: 8000 entries, routing/switching capacity: 20 Gbit/s. Network standard: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav. Rack installation, Form factor: 1U
Podijelite:Cudy GS2024S2. Switch type: Managed, Switch level: L2/L3. Basic Switching RJ-45 Ethernet Ports type: Gigabit Ethernet (10/100/1000), Number of basic switching RJ-45 Ethernet ports: 24, Number of installed SFP modules: 4, console port: RJ-45. MAC address table: 8000 entries, routing/switching capacity: 20 Gbit/s. Network standard: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav. Rack installation, Form factor: 1U
management functions
Switch Type: Managed
Switch level: L2/L3
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Property: Traffic Classification
Property: System Event Log
connections and interfaces
Number of base-switching RJ-45 Ethernet ports: 24
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of Gigabit Ethernet (copper) ports: 24
Number of installed SFP modules: 4
Console port: RJ-45
network
Network standard: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav
supported cable types: Cat3, Cat4, Cat5
Property: Port Mirroring
Property: IP routing
Feature: Support data flow control
Property: Link Aggregation
Property: Broadcast Storm Control
Property: Rate Limiting
Property: Spanning Tree Protocol
Ethernet LAN data transfer rates: 10,100,1000 Mbit/s
Feature: Self-learning of MAC addresses supported
Feature: Auto-aging of MAC addresses supported
Feature: VLAN support
Virtual LAN features: Voice VLAN
Number of VLANs: 4096
optical fiber
Fiber type: Multi-mode
data transfer
Routing/switching capacity: 20 Gbit/s
Transfer rate: 14.88 Mpps
MAC address table: 8000 entries
Property: Static Route
Feature: Jumbo Frames Support
Jumbo frames: 9.6
Data packet buffer memory: 0.5 MB
Security
DHCP functions: DHCP Option 82, DHCP server, DHCP snooping
Property: IGMP snooping
Feature: SSH/SSL support
Property: IP-MAC port binding
Authentication: Port-based authentication
Authentication type: AAA, TACACS+
multicast functions
Feature: Multicast support
protocols
IPv4 & IPv6 features: IPv6 Telnet
design
Feature: Rack installation
Feature: Stackable
Form factor: 1U
Product color: Black
LED indicators: Activity, Link, Power, System
services
Memory type: DDR-SDRAM
Storage capacity: 128 MB
Flash memory: 16 MB
energy
Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
operating conditions
Operating temperature: -10 - 50 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 10 - 90%
Humidity during storage: 5 - 90%
weight and dimensions
Width: 440 mm
Depth: 204 mm
Height: 44 mm
Weight: 2.45 kg
packaging data
Packaging type: Box
Packaging width: 500 mm
Packaging depth: 290 mm
Packaging height: 85 mm
Package weight: 3.06 kg
Switch Type: Managed
Switch level: L2/L3
Feature: Quality of Service (QoS) Support
Feature: Web-based management
Property: Traffic Classification
Property: System Event Log
connections and interfaces
Number of base-switching RJ-45 Ethernet ports: 24
Basic Switching RJ-45 Ethernet Ports Type: Gigabit Ethernet (10/100/1000)
Number of Gigabit Ethernet (copper) ports: 24
Number of installed SFP modules: 4
Console port: RJ-45
network
Network standard: IEEE 802.11j, IEEE 802.11k, IEEE 802.1Qav
supported cable types: Cat3, Cat4, Cat5
Property: Port Mirroring
Property: IP routing
Feature: Support data flow control
Property: Link Aggregation
Property: Broadcast Storm Control
Property: Rate Limiting
Property: Spanning Tree Protocol
Ethernet LAN data transfer rates: 10,100,1000 Mbit/s
Feature: Self-learning of MAC addresses supported
Feature: Auto-aging of MAC addresses supported
Feature: VLAN support
Virtual LAN features: Voice VLAN
Number of VLANs: 4096
optical fiber
Fiber type: Multi-mode
data transfer
Routing/switching capacity: 20 Gbit/s
Transfer rate: 14.88 Mpps
MAC address table: 8000 entries
Property: Static Route
Feature: Jumbo Frames Support
Jumbo frames: 9.6
Data packet buffer memory: 0.5 MB
Security
DHCP functions: DHCP Option 82, DHCP server, DHCP snooping
Property: IGMP snooping
Feature: SSH/SSL support
Property: IP-MAC port binding
Authentication: Port-based authentication
Authentication type: AAA, TACACS+
multicast functions
Feature: Multicast support
protocols
IPv4 & IPv6 features: IPv6 Telnet
design
Feature: Rack installation
Feature: Stackable
Form factor: 1U
Product color: Black
LED indicators: Activity, Link, Power, System
services
Memory type: DDR-SDRAM
Storage capacity: 128 MB
Flash memory: 16 MB
energy
Power source: AC
Feature: Power supply included
AC input voltage: 100 - 240 V
operating conditions
Operating temperature: -10 - 50 °C
Storage temperature range: -40 - 70 °C
Relative humidity during operation: 10 - 90%
Humidity during storage: 5 - 90%
weight and dimensions
Width: 440 mm
Depth: 204 mm
Height: 44 mm
Weight: 2.45 kg
packaging data
Packaging type: Box
Packaging width: 500 mm
Packaging depth: 290 mm
Packaging height: 85 mm
Package weight: 3.06 kg
