1000W, ATX 3.0, 100 - 240V, 50 - 60Hz, 160x150x86mm, Black
be quiet! Pure Power 12 M, 1000 W, 100 - 240 V, 1050 W, 50/60 Hz, 12 / 6 A, Active
be quiet! Pure Power 12 M. Total power: 1000 W, AC input voltage: 100 - 240 V, peak current: 1050 W. Motherboard connector plug: 20+4 pin ATX, motherboard power cable length: 55 cm, SATA power cable length: 500,600,650,800,950 mm. Purpose: PC, Power Supply Unit (PSU) Form Factor: ATX, 80 Plus Certification: 80 PLUS Gold. Color of product: Black, Cooling: Active, Fan diameter: 12 cm. Cables included: PATA, PCIe, Peripheral (Molex), SATA
Podijelite:be quiet! Pure Power 12 M, 1000 W, 100 - 240 V, 1050 W, 50/60 Hz, 12 / 6 A, Active
be quiet! Pure Power 12 M. Total power: 1000 W, AC input voltage: 100 - 240 V, peak current: 1050 W. Motherboard connector plug: 20+4 pin ATX, motherboard power cable length: 55 cm, SATA power cable length: 500,600,650,800,950 mm. Purpose: PC, Power Supply Unit (PSU) Form Factor: ATX, 80 Plus Certification: 80 PLUS Gold. Color of product: Black, Cooling: Active, Fan diameter: 12 cm. Cables included: PATA, PCIe, Peripheral (Molex), SATA
EXCEPTIONALLY QUIET, SUPERIOR FEATURES
Pure Power 12M 1000W is ATX 3.0 and PCIe 5.0 compatible and offers unparalleled reliability with premium features. Pure Power 12M 1000W offers the best possible combination of features with outstanding compatibility.
80 PLUS GOLD CERTIFICATION
Very high efficiency
The Pure Power 12 M 1000W is 80 PLUS Gold certified and achieves an outstanding efficiency of 93.1%. And it's worth it: less energy consumption means lower costs, better cooling and quieter operation. Pure Power 12 M 1000W is the right choice for all quiet and gaming-oriented systems!
GET YOUR SYSTEM READY FOR THE FUTURE
Meets all ATX 3.0 specifications
Pure Power 12M 1000W is an ATX 3.0 power supply and comes with a 12VHPWR connector for next-gen PCIe 5.0 graphics cards and PCIe 6+2 connectors for current graphics cards. This makes the Pure Power 12 M 1000W extremely versatile and the perfect choice for all current and future-proof high-end systems.
THE NEW PERFORMANCE STANDARD
For huge peak loads
Pure Power 12 M offers 1000W of continuous power on 2 independent 12V rails. Even if the graphics card demands excessive performance for short periods of time: The Pure Power 12 M 1000W can handle peak loads of up to twice the nominal load without any problems. This ensures reliable operation with the next generations of processors and graphics cards.
EXCEPTIONALLY QUIET OPERATION
Achieved by the noise-optimized 120mm
be quiet! Fan
The extraordinarily quiet 120mm be quiet! fan achieves the best possible balance between effective cooling and quiet operation. The airflow-optimized fan blades, which reduce noise-causing turbulence, achieve the extremely quiet operation for which be quiet!
is so well known.
HIGH CLASS TECHNOLOGY
Rock solid stability
Thanks to LLC topology, the Pure Power 12 M 1000W offers first-class voltage regulation. Therefore, it is the best choice for building very quiet systems, as well as upgrading gaming PCs and media editing PCs.
MODULAR CABLES
Maximum comfort and compatibility
Only the cables that are really needed are used! Laying the cables is very easy with the Pure Power 12 M 1000W. The advantage: a tidy housing and an undisturbed air flow, which leads to lower system temperatures and an overall
results in quieter operation.
Pure Power 12M 1000W is ATX 3.0 and PCIe 5.0 compatible and offers unparalleled reliability with premium features. Pure Power 12M 1000W offers the best possible combination of features with outstanding compatibility.
80 PLUS GOLD CERTIFICATION
Very high efficiency
The Pure Power 12 M 1000W is 80 PLUS Gold certified and achieves an outstanding efficiency of 93.1%. And it's worth it: less energy consumption means lower costs, better cooling and quieter operation. Pure Power 12 M 1000W is the right choice for all quiet and gaming-oriented systems!
GET YOUR SYSTEM READY FOR THE FUTURE
Meets all ATX 3.0 specifications
Pure Power 12M 1000W is an ATX 3.0 power supply and comes with a 12VHPWR connector for next-gen PCIe 5.0 graphics cards and PCIe 6+2 connectors for current graphics cards. This makes the Pure Power 12 M 1000W extremely versatile and the perfect choice for all current and future-proof high-end systems.
THE NEW PERFORMANCE STANDARD
For huge peak loads
Pure Power 12 M offers 1000W of continuous power on 2 independent 12V rails. Even if the graphics card demands excessive performance for short periods of time: The Pure Power 12 M 1000W can handle peak loads of up to twice the nominal load without any problems. This ensures reliable operation with the next generations of processors and graphics cards.
EXCEPTIONALLY QUIET OPERATION
Achieved by the noise-optimized 120mm
be quiet! Fan
The extraordinarily quiet 120mm be quiet! fan achieves the best possible balance between effective cooling and quiet operation. The airflow-optimized fan blades, which reduce noise-causing turbulence, achieve the extremely quiet operation for which be quiet!
is so well known.
HIGH CLASS TECHNOLOGY
Rock solid stability
Thanks to LLC topology, the Pure Power 12 M 1000W offers first-class voltage regulation. Therefore, it is the best choice for building very quiet systems, as well as upgrading gaming PCs and media editing PCs.
MODULAR CABLES
Maximum comfort and compatibility
Only the cables that are really needed are used! Laying the cables is very easy with the Pure Power 12 M 1000W. The advantage: a tidy housing and an undisturbed air flow, which leads to lower system temperatures and an overall
results in quieter operation.
Performance
Total power: 1000W
AC Input Voltage: 100-240V
Peak Power: 1050W
AC input frequency: 50/60 Hz
Input current: 12 / 6 A
Power Factor: 0.98
Power Factor Correction Filter (PFC): Active
Combined power (+3.3V): 120 W
Combined power (+12V): 1000 W
Combined power (+5V): 120 W
Combined Power (-12V): 3.6W
Combined power (+5Vsb): 15 W
Max. output current (+3.3V): 22 A
Max. output current (+12V): 83.4 A
Max. output current (+12V1): 46 A
Max output current (+12V2): 42 A
Max output current (+5V): 22 A
Max. output current (-12V): 0.3A
Max. output current (+5Vsb): 3A
Efficiency: 93.2%
Power Good Signal Delay Range: 100 - 150ms
Power protection features: over current, overload, over voltage, over heat, short circuit
connections and interfaces
Motherboard connector: 20+4 pin ATX
Number of Molex connectors 4pin: 1
Motherboard power cable length: 55 cm
Number of SATA power connectors: 6
Number of PATA power connections: 2
SATA Power Cable Length: 500,600,650,800,950mm
Peripheral (Molex) power cord length: 550mm
EPS Power Connector (8-pin): Yes
EPS Power Connector (4+4 pin): Yes
Number of PCI Express power connectors 6+2pin: 4
ATX power connector (20+4 pin): Yes
PCI Express connector: Yes
Services
Purpose: personal computer
Power supply unit (PSU) form factor: ATX
80 Plus Certification: 80 PLUS Gold
ATX Version: 3.0
EPS version: 2.92
Noise level: 31.7dB
Mean time between failures (MTBF): 100000 h
design
Color of product: Black
Cooling: Active
Fan diameter: 12 cm
Number of fans: 1 fan
Fan Placement: Top
On/off switch: Yes
operating conditions
Operating temperature: 0 - 40 °C
weight and dimensions
Width: 160mm
Depth: 150mm
Height: 86mm
packaging data
Packing type: box
Technical details
Sustainability Compliance: Yes
Sustainability certificates: ENERGY STAR, ErP, RoHS
Warranty period: 10 year(s)
Other functions
Screws Included: Yes
Number of screws: 5
Cable ties included: Yes
Noise level (quiet mode, <30%): 9.3 dB
Noise level (sleep mode, 50%): 9.6 dB
Noise level (full load mode, 100%): 31.7 dB
Total power: 1000W
AC Input Voltage: 100-240V
Peak Power: 1050W
AC input frequency: 50/60 Hz
Input current: 12 / 6 A
Power Factor: 0.98
Power Factor Correction Filter (PFC): Active
Combined power (+3.3V): 120 W
Combined power (+12V): 1000 W
Combined power (+5V): 120 W
Combined Power (-12V): 3.6W
Combined power (+5Vsb): 15 W
Max. output current (+3.3V): 22 A
Max. output current (+12V): 83.4 A
Max. output current (+12V1): 46 A
Max output current (+12V2): 42 A
Max output current (+5V): 22 A
Max. output current (-12V): 0.3A
Max. output current (+5Vsb): 3A
Efficiency: 93.2%
Power Good Signal Delay Range: 100 - 150ms
Power protection features: over current, overload, over voltage, over heat, short circuit
connections and interfaces
Motherboard connector: 20+4 pin ATX
Number of Molex connectors 4pin: 1
Motherboard power cable length: 55 cm
Number of SATA power connectors: 6
Number of PATA power connections: 2
SATA Power Cable Length: 500,600,650,800,950mm
Peripheral (Molex) power cord length: 550mm
EPS Power Connector (8-pin): Yes
EPS Power Connector (4+4 pin): Yes
Number of PCI Express power connectors 6+2pin: 4
ATX power connector (20+4 pin): Yes
PCI Express connector: Yes
Services
Purpose: personal computer
Power supply unit (PSU) form factor: ATX
80 Plus Certification: 80 PLUS Gold
ATX Version: 3.0
EPS version: 2.92
Noise level: 31.7dB
Mean time between failures (MTBF): 100000 h
design
Color of product: Black
Cooling: Active
Fan diameter: 12 cm
Number of fans: 1 fan
Fan Placement: Top
On/off switch: Yes
operating conditions
Operating temperature: 0 - 40 °C
weight and dimensions
Width: 160mm
Depth: 150mm
Height: 86mm
packaging data
Packing type: box
Technical details
Sustainability Compliance: Yes
Sustainability certificates: ENERGY STAR, ErP, RoHS
Warranty period: 10 year(s)
Other functions
Screws Included: Yes
Number of screws: 5
Cable ties included: Yes
Noise level (quiet mode, <30%): 9.3 dB
Noise level (sleep mode, 50%): 9.6 dB
Noise level (full load mode, 100%): 31.7 dB
