be quiet! Pure Power 12 M, 1000 W, 100-240 V, 1050 W, 50-60 Hz, 12/6 A, Active be quiet! Pure Power 12 M. Total power: 1000 W, AC input voltage: 100-240 V, Peak current: 1050 W. Motherboard connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500, 600, 650, 800, 950 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 Plus certification: 80 PLUS Gold. Product color: Black, Cooling: Active, Fan diameter: 12 cm. Included cables: PATA, PCIe, Peripheral (Molex), SATA
Podijelite:
EXTRAORDINARY QUIET, SUPERIOR FEATURES
The Pure Power 12 M 1000W is ATX 3.1 and PCIe 5.1 compatible and offers unparalleled reliability with premium features. The Pure Power 12 M 1000W offers the best possible combination of features with outstanding compatibility.
80 PLUS GOLD CERTIFICATION
Very high efficiency
The Pure Power 12 M 1000W is 80 PLUS Gold certified and achieves an outstanding efficiency of 93.1%. And it“s worth it: Lower energy consumption leads to lower costs, better cooling, and quieter operation. The Pure Power 12 M 1000W is the right choice for all quiet, gaming-focused systems!
MAKE YOUR SYSTEM READY FOR THE FUTURE
Meets all ATX 3.1 specifications
The Pure Power 12 M 1000W is an ATX 3.1 power supply and features a 12V 2x6 connector for next-gen PCIe 5.1 graphics cards and PCIe 6+2 connectors for current graphics cards. This makes the Pure Power 12 M 1000W extremely versatile and the perfect choice for all current and future-proof high-end systems.
THE NEW PERFORMANCE STANDARD
For huge load peaks
The Pure Power 12 M offers 1000W of continuous power on two independent 12V rails. Even if the graphics card draws excessive power for short periods, the Pure Power 12 M 1000W can easily handle peak loads of up to twice the rated load. This ensures reliable operation with next-generation processors and graphics cards.
EXCEPTIONALLY QUIET OPERATION
Achieved by the noise-optimized 120mm
be quiet! fan
The exceptionally quiet 120mm be quiet! fan achieves the best possible balance between effective cooling and quiet operation. The airflow-optimized fan blades, which reduce noise-causing turbulence, achieve the exceptionally quiet operation for which be quiet! is renowned.
is so well known.
HIGH-CLASS TECHNOLOGY
Rock-solid stability
Thanks to LLC topology, the Pure Power 12 M 1000W offers first-class voltage regulation. This makes it the ideal choice for building ultra-quiet systems, as well as upgrading gaming and media editing PCs.
MODULAR CABLES
Maximum comfort and compatibility
Only the cables that are really needed are used! Laying the cables is incredibly easy with the Pure Power 12 M 1000W. The advantage: a tidy case and uninterrupted airflow, which leads to lower system temperatures and an overall
leads to quieter operation.
The Pure Power 12 M 1000W is ATX 3.1 and PCIe 5.1 compatible and offers unparalleled reliability with premium features. The Pure Power 12 M 1000W offers the best possible combination of features with outstanding compatibility.
80 PLUS GOLD CERTIFICATION
Very high efficiency
The Pure Power 12 M 1000W is 80 PLUS Gold certified and achieves an outstanding efficiency of 93.1%. And it“s worth it: Lower energy consumption leads to lower costs, better cooling, and quieter operation. The Pure Power 12 M 1000W is the right choice for all quiet, gaming-focused systems!
MAKE YOUR SYSTEM READY FOR THE FUTURE
Meets all ATX 3.1 specifications
The Pure Power 12 M 1000W is an ATX 3.1 power supply and features a 12V 2x6 connector for next-gen PCIe 5.1 graphics cards and PCIe 6+2 connectors for current graphics cards. This makes the Pure Power 12 M 1000W extremely versatile and the perfect choice for all current and future-proof high-end systems.
THE NEW PERFORMANCE STANDARD
For huge load peaks
The Pure Power 12 M offers 1000W of continuous power on two independent 12V rails. Even if the graphics card draws excessive power for short periods, the Pure Power 12 M 1000W can easily handle peak loads of up to twice the rated load. This ensures reliable operation with next-generation processors and graphics cards.
EXCEPTIONALLY QUIET OPERATION
Achieved by the noise-optimized 120mm
be quiet! fan
The exceptionally quiet 120mm be quiet! fan achieves the best possible balance between effective cooling and quiet operation. The airflow-optimized fan blades, which reduce noise-causing turbulence, achieve the exceptionally quiet operation for which be quiet! is renowned.
is so well known.
HIGH-CLASS TECHNOLOGY
Rock-solid stability
Thanks to LLC topology, the Pure Power 12 M 1000W offers first-class voltage regulation. This makes it the ideal choice for building ultra-quiet systems, as well as upgrading gaming and media editing PCs.
MODULAR CABLES
Maximum comfort and compatibility
Only the cables that are really needed are used! Laying the cables is incredibly easy with the Pure Power 12 M 1000W. The advantage: a tidy case and uninterrupted airflow, which leads to lower system temperatures and an overall
leads to quieter operation.
energy
Total power: 1000 W
Peak current: 1050 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 12 / 6 A
Power factor: 0.98
Power factor correction filter (PFC): Active
Combined current (+3.3V): 120 W
Combined current (+12V): 1000 W
Combined current (+5V): 120 W
Combined current (-12V): 3.6 W
Combined current (+5Vsb): 15 W
Max. output current (+3.3V): 22 A
Max. output current (+12V): 83.4 A
Max. output current (+12V1): 46 A
Max output current (+12V2): 42 A
Max output current (+5V): 22 A
Max. output current (-12V): 0.3 A
Max. output current (+5Vsb): 3 A
Efficiency: 93.2%
Power Good Signal Delay Range: 100 - 150 ms
Energy protection features: overcurrent, overload, overvoltage, overheating, short circuit
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 55 cm
Number of SATA power connectors: 6
Number of PATA power connections: 2
SATA power cable length: 500, 600, 650, 800, 950 mm
Number of Molex connectors 4-pin: 1
Peripheral (Molex) power cable length: 550 mm
Feature: EPS power connector (8-pin)
Feature: EPS power connector (4+4 pin)
Number of PCI Express power connectors 6+2pin: 4
PCI Express power cable length: 65 cm
Feature: ATX power connector (20+4 pin)
Feature: PCI Express connector
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
EPS version: 2.92
Noise level: 31.7 dB
Mean time between failures (MTBF): 100,000 h
design
Product color: Black
Cooling: Active
Fan diameter: 12 cm
Number of fans: 1 fan
Fan speed: 0 - 2000 RPM
Fan placement: Top
Feature: On/Off switch
Operating conditions
Operating temperature: 0 - 40 °C
Scope of delivery
Included cables: PATA, PCIe, Peripheral (Molex), SATA
Certificates
Certificates of Conformity: RoHS
Weight and dimensions
Width: 160 mm
Depth: 150 mm
Height: 86 mm
Packaging data
Packaging type: Box
Technical details
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR, ErP
Logistics data
Warranty period: 10 year(s)
Other functions
Feature: Screws included
Number of screws: 5
Feature: Cable ties included
Noise level (quiet mode, <30%): 9.3 dB
Noise level (sleep mode, 50%): 9.6 dB
Noise level (full load mode, 100%): 31.7 dB
Total power: 1000 W
Peak current: 1050 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Input current: 12 / 6 A
Power factor: 0.98
Power factor correction filter (PFC): Active
Combined current (+3.3V): 120 W
Combined current (+12V): 1000 W
Combined current (+5V): 120 W
Combined current (-12V): 3.6 W
Combined current (+5Vsb): 15 W
Max. output current (+3.3V): 22 A
Max. output current (+12V): 83.4 A
Max. output current (+12V1): 46 A
Max output current (+12V2): 42 A
Max output current (+5V): 22 A
Max. output current (-12V): 0.3 A
Max. output current (+5Vsb): 3 A
Efficiency: 93.2%
Power Good Signal Delay Range: 100 - 150 ms
Energy protection features: overcurrent, overload, overvoltage, overheating, short circuit
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 55 cm
Number of SATA power connectors: 6
Number of PATA power connections: 2
SATA power cable length: 500, 600, 650, 800, 950 mm
Number of Molex connectors 4-pin: 1
Peripheral (Molex) power cable length: 550 mm
Feature: EPS power connector (8-pin)
Feature: EPS power connector (4+4 pin)
Number of PCI Express power connectors 6+2pin: 4
PCI Express power cable length: 65 cm
Feature: ATX power connector (20+4 pin)
Feature: PCI Express connector
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
EPS version: 2.92
Noise level: 31.7 dB
Mean time between failures (MTBF): 100,000 h
design
Product color: Black
Cooling: Active
Fan diameter: 12 cm
Number of fans: 1 fan
Fan speed: 0 - 2000 RPM
Fan placement: Top
Feature: On/Off switch
Operating conditions
Operating temperature: 0 - 40 °C
Scope of delivery
Included cables: PATA, PCIe, Peripheral (Molex), SATA
Certificates
Certificates of Conformity: RoHS
Weight and dimensions
Width: 160 mm
Depth: 150 mm
Height: 86 mm
Packaging data
Packaging type: Box
Technical details
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR, ErP
Logistics data
Warranty period: 10 year(s)
Other functions
Feature: Screws included
Number of screws: 5
Feature: Cable ties included
Noise level (quiet mode, <30%): 9.3 dB
Noise level (sleep mode, 50%): 9.6 dB
Noise level (full load mode, 100%): 31.7 dB
