ASUS TUF Gaming 1000W Gold, 1000 W, 100-240 V, 130 W, 1000 W, 130 W, 9.6 W ASUS TUF Gaming 1000W Gold. Total power: 1000 W, AC input voltage: 100-240 V, Combined power (+3.3V): 130 W. Motherboard connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 120, 400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 Plus certification: 80 PLUS Gold. Product color: Black, Cooling: Active, Fan diameter: 13.5 cm. Included cables: AC, CPU, PCIe, Peripheral (Molex), SATA
Podijelite:
Built to last
The ASUS TUF Gaming 1000W Gold offers military-grade strength, a flagship fan design, and PCB protection for an efficient, long-lasting power supply. The result is a power supply that will reliably power your system for years to come.
longevity
TUF components
Top marks
With military-grade components, including capacitors rated for operation at 105°C and a lifespan of up to 170,000 hours, the ASUS TUF Gaming 1000W Gold lets you confidently build your new system.
Double ball bearing fan
2x longer life expectancy
Exemplary cooling is provided by a 135 mm fan equipped with a double ball bearing that lasts up to twice as long as a sleeve bearing design.
PCB protective coating
Completely wrapped
A conformal protective layer surrounds the circuit board and protects it from short circuits caused by moisture, dust and dirt.
ENGINEERING
80 Plus Gold Certification
Heart of Gold
The TUF Gaming 1000W Gold Aura Edition features efficient Japanese capacitors with low ESR, ensuring efficient operation and earning it 80 PLUS® Gold status. This means it has an efficiency of up to 92%, resulting in less heat, less fan noise, and greater reliability.
ATX 3.1 Compatible
A step into the future
The latest performance updates are in. ATX 3.1 introduces stricter voltage and current regulation guidelines for next-generation hardware—and the TUF Gaming 1000W Gold is one step ahead of this trend, fully compliant. The power supply comes with a 16-pin PCIe cable, allowing for up to 600W of power to be sent to PCIe Gen 5.0 graphics cards, enabling significant performance.
Axial-Tech fan design
Better, faster, stronger
The Axial-Tech fan design features a smaller fan hub that allows for longer blades and a locking ring that increases downward air pressure. For the TUF Gaming series power supplies, we scaled the design to 135 mm to keep it cool and quiet even at low speeds.
EXPERIENCE
10-year warranty
A decade of power
We“re so confident in the reliability of the TUF Gaming 1000W Gold that we back it with a 10-year worldwide warranty.
Fully modular etched cables
Smooth location
The included fully modular cable set is etched to provide a similar aesthetic to sleeved cables, but a touch more flexibility for tight spaces.
The ASUS TUF Gaming 1000W Gold offers military-grade strength, a flagship fan design, and PCB protection for an efficient, long-lasting power supply. The result is a power supply that will reliably power your system for years to come.
longevity
TUF components
Top marks
With military-grade components, including capacitors rated for operation at 105°C and a lifespan of up to 170,000 hours, the ASUS TUF Gaming 1000W Gold lets you confidently build your new system.
Double ball bearing fan
2x longer life expectancy
Exemplary cooling is provided by a 135 mm fan equipped with a double ball bearing that lasts up to twice as long as a sleeve bearing design.
PCB protective coating
Completely wrapped
A conformal protective layer surrounds the circuit board and protects it from short circuits caused by moisture, dust and dirt.
ENGINEERING
80 Plus Gold Certification
Heart of Gold
The TUF Gaming 1000W Gold Aura Edition features efficient Japanese capacitors with low ESR, ensuring efficient operation and earning it 80 PLUS® Gold status. This means it has an efficiency of up to 92%, resulting in less heat, less fan noise, and greater reliability.
ATX 3.1 Compatible
A step into the future
The latest performance updates are in. ATX 3.1 introduces stricter voltage and current regulation guidelines for next-generation hardware—and the TUF Gaming 1000W Gold is one step ahead of this trend, fully compliant. The power supply comes with a 16-pin PCIe cable, allowing for up to 600W of power to be sent to PCIe Gen 5.0 graphics cards, enabling significant performance.
Axial-Tech fan design
Better, faster, stronger
The Axial-Tech fan design features a smaller fan hub that allows for longer blades and a locking ring that increases downward air pressure. For the TUF Gaming series power supplies, we scaled the design to 135 mm to keep it cool and quiet even at low speeds.
EXPERIENCE
10-year warranty
A decade of power
We“re so confident in the reliability of the TUF Gaming 1000W Gold that we back it with a 10-year worldwide warranty.
Fully modular etched cables
Smooth location
The included fully modular cable set is etched to provide a similar aesthetic to sleeved cables, but a touch more flexibility for tight spaces.
energy
Total power: 1000 W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 130 W
Combined power (+12V): 1000 W
Combined power (+5V): 130 W
Combined power (-12V): 9.6 W
Combined power (+5Vsb): 15 W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 83.3 A
Maximum output current (+5V): 25 A
Max. output current (-12V): 0.8 A
Max. output current (+5Vsb): 3 A
Efficiency: 92%
Energy protection features: Overload, overvoltage, overload, overheating, short circuit, undercurrent, undervoltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 5
SATA power cable length: 120.400 mm
Number of Molex 4-pin connectors: 4
Peripheral (Molex) power cable length: 150,400 mm
Number of PCI Express 8-pin power connectors: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 67.5 cm
CPU connector (4+4 pin): Yes
CPU performance Cable length: 65 cm
ATX power connector (20+4 pin): Yes
PCI Express connector: Yes
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power Supply Unit (PSU) Form Factor: ATX
ATX version: 3.1
design
Product color: Black
Cooling: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan
Lighting: No
On/off switch: Yes
Scope of delivery
Included cables: AC, CPU, PCIe, Peripheral (Molex), SATA
Cable ties included: Yes
Certificates
Certificates of conformity: RoHS
Weight and dimensions
Width: 150 mm
Depth: 150 mm
Height: 86 mm
Weight: 2.48 kg
Packaging data
Packaging width: 310 mm
Packaging depth: 200 mm
Packaging height: 108 mm
Package weight: 3.17 kg
Packaging type: Box
Technical details
Sustainability compliance: Yes
Total power: 1000 W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 130 W
Combined power (+12V): 1000 W
Combined power (+5V): 130 W
Combined power (-12V): 9.6 W
Combined power (+5Vsb): 15 W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 83.3 A
Maximum output current (+5V): 25 A
Max. output current (-12V): 0.8 A
Max. output current (+5Vsb): 3 A
Efficiency: 92%
Energy protection features: Overload, overvoltage, overload, overheating, short circuit, undercurrent, undervoltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 5
SATA power cable length: 120.400 mm
Number of Molex 4-pin connectors: 4
Peripheral (Molex) power cable length: 150,400 mm
Number of PCI Express 8-pin power connectors: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 67.5 cm
CPU connector (4+4 pin): Yes
CPU performance Cable length: 65 cm
ATX power connector (20+4 pin): Yes
PCI Express connector: Yes
Cable type: Fully modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power Supply Unit (PSU) Form Factor: ATX
ATX version: 3.1
design
Product color: Black
Cooling: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan
Lighting: No
On/off switch: Yes
Scope of delivery
Included cables: AC, CPU, PCIe, Peripheral (Molex), SATA
Cable ties included: Yes
Certificates
Certificates of conformity: RoHS
Weight and dimensions
Width: 150 mm
Depth: 150 mm
Height: 86 mm
Weight: 2.48 kg
Packaging data
Packaging width: 310 mm
Packaging depth: 200 mm
Packaging height: 108 mm
Package weight: 3.17 kg
Packaging type: Box
Technical details
Sustainability compliance: Yes
