eGarner webshop - Napajanja
ASUS TUF Gaming 1000W Gold, 1000W, 100 - 240V, 130W, 1000W, 130W, 9.6W
ASUS TUF Gaming 1000W Gold. Total power: 1000 W, AC input voltage: 100 - 240 V, Combined power (+3.3V): 130 W. Motherboard connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power Supply Unit (PSU) Form factor: ATX, 80 Plus Certification: 80 PLUS Gold. Product color: Black, Cooling: Active, Fan diameter: 13.5 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Podijelite:ASUS TUF Gaming 1000W Gold. Total power: 1000 W, AC input voltage: 100 - 240 V, Combined power (+3.3V): 130 W. Motherboard connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power Supply Unit (PSU) Form factor: ATX, 80 Plus Certification: 80 PLUS Gold. Product color: Black, Cooling: Active, Fan diameter: 13.5 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Built to last
The ASUS TUF Gaming 1000W Gold offers military strength, a flagship fan design and PCB protection for efficient, long-lasting power. The result is a power supply that will reliably supply your system with energy for years to come.
longevity
TUF components
Top marks
With military-grade components, including capacitors rated to operate at 105°C and last up to 170,000 hours, the ASUS TUF Gaming 1000W Gold lets you build your new system with confidence.
Double ball bearing fan
2x longer life expectancy
Providing exemplary cooling is a 135mm fan equipped with a dual ball bearing that lasts up to twice as long as a plain bearing design.
PCB protective coating
Completely covered
A conformal protective layer surrounds the circuit board and protects it from short circuits caused by moisture, dust and dirt.
ENGINEERING
80 Plus Gold Certification
heart of gold
The TUF Gaming 1000W Gold Aura Edition features efficient, low ESR Japanese capacitors that ensure efficient operation and give it 80 PLUS® Gold status. This means it has up to 92% efficiency, resulting in less heat, less fan noise and higher reliability.
ATX 3.0 compatible
A step into the future
The latest performance data updates are here. ATX 3.0 introduces stricter voltage and current regulation guidelines for next-generation hardware - and the TUF Gaming 1000W Gold is one step ahead of this development by being fully compliant. Included with the power supply is a 16-pin PCIe cable that can deliver up to 600W of power to PCIe Gen 5.0 graphics cards, enabling great performance.
Axial-Tech fan design
Better, faster, stronger
The Axial-Tech fan design features a smaller fan hub that allows for longer blades and a barrier ring that increases downward air pressure. For the TUF Gaming series PSUs, we scaled the design to 135mm to keep it cool at low speeds and produce less noise.
EXPERIENCE
10 year guarantee
A decade of power
We“re so confident in the reliability of the TUF Gaming 1000W Gold that we back it with a 10-year worldwide warranty.
Fully modular etched cables
Supple location
The included fully modular cable set is etched to provide a similar aesthetic to sleeved cables, but a touch more flexibility for tight spaces.
The ASUS TUF Gaming 1000W Gold offers military strength, a flagship fan design and PCB protection for efficient, long-lasting power. The result is a power supply that will reliably supply your system with energy for years to come.
longevity
TUF components
Top marks
With military-grade components, including capacitors rated to operate at 105°C and last up to 170,000 hours, the ASUS TUF Gaming 1000W Gold lets you build your new system with confidence.
Double ball bearing fan
2x longer life expectancy
Providing exemplary cooling is a 135mm fan equipped with a dual ball bearing that lasts up to twice as long as a plain bearing design.
PCB protective coating
Completely covered
A conformal protective layer surrounds the circuit board and protects it from short circuits caused by moisture, dust and dirt.
ENGINEERING
80 Plus Gold Certification
heart of gold
The TUF Gaming 1000W Gold Aura Edition features efficient, low ESR Japanese capacitors that ensure efficient operation and give it 80 PLUS® Gold status. This means it has up to 92% efficiency, resulting in less heat, less fan noise and higher reliability.
ATX 3.0 compatible
A step into the future
The latest performance data updates are here. ATX 3.0 introduces stricter voltage and current regulation guidelines for next-generation hardware - and the TUF Gaming 1000W Gold is one step ahead of this development by being fully compliant. Included with the power supply is a 16-pin PCIe cable that can deliver up to 600W of power to PCIe Gen 5.0 graphics cards, enabling great performance.
Axial-Tech fan design
Better, faster, stronger
The Axial-Tech fan design features a smaller fan hub that allows for longer blades and a barrier ring that increases downward air pressure. For the TUF Gaming series PSUs, we scaled the design to 135mm to keep it cool at low speeds and produce less noise.
EXPERIENCE
10 year guarantee
A decade of power
We“re so confident in the reliability of the TUF Gaming 1000W Gold that we back it with a 10-year worldwide warranty.
Fully modular etched cables
Supple location
The included fully modular cable set is etched to provide a similar aesthetic to sleeved cables, but a touch more flexibility for tight spaces.
energy
Total power: 1000W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 130W
Combined power (+12V): 1000 W
Combined power (+5V): 130W
Combined power (-12V): 9.6W
Combined current (+5Vsb): 15W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 83.3 A
Max output current (+5V): 25A
Max. output current (-12V): 0.8A
Max. output current (+5Vsb): 3 A
Efficiency: 92%
Energy protection properties: overload, overvoltage, overload, overheating, short circuit, under current, under voltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 5
SATA power cable length: 120,400mm
Number of Molex connectors 4pin: 4
Peripheral (Molex) power cable length: 150,400 mm
Number of PCI Express power connectors 8pin: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 67.5 cm
Feature: CPU connector (4+4 pin)
CPU performance Cable length: 65 cm
Feature: ATX power connector (20+4 pin)
Cable Type: Modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power Supply Unit (PSU) Form Factor: ATX
ATX version: 3.0
design
Product color: Black
Cooling: Active
Fan diameter: 13.5cm
Number of fans: 1 fan
Feature: on/off switch
scope of delivery
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Feature: Cable ties included
Weight and dimensions
Width: 150mm
Depth: 150mm
Height: 86mm
Weight: 2.48kg
Packaging data
Packaging width: 310 mm
Packaging depth: 200 mm
Packaging height: 108 mm
Package weight: 3.17 kg
Packaging type: box
Technical details
Feature: Sustainability compliance
Sustainability certificates: RoHS
Total power: 1000W
AC input voltage: 100 - 240 V
Combined power (+3.3V): 130W
Combined power (+12V): 1000 W
Combined power (+5V): 130W
Combined power (-12V): 9.6W
Combined current (+5Vsb): 15W
Max. output current (+3.3V): 25 A
Max. output current (+12V): 83.3 A
Max output current (+5V): 25A
Max. output current (-12V): 0.8A
Max. output current (+5Vsb): 3 A
Efficiency: 92%
Energy protection properties: overload, overvoltage, overload, overheating, short circuit, under current, under voltage
Connections and interfaces
Motherboard connector: 20+4 pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 5
SATA power cable length: 120,400mm
Number of Molex connectors 4pin: 4
Peripheral (Molex) power cable length: 150,400 mm
Number of PCI Express power connectors 8pin: 4
PCI Express power connectors (16-pin): 1
PCI Express power cable length: 67.5 cm
Feature: CPU connector (4+4 pin)
CPU performance Cable length: 65 cm
Feature: ATX power connector (20+4 pin)
Cable Type: Modular
Services
80 Plus Certification: 80 PLUS Gold
Purpose: PC
Power Supply Unit (PSU) Form Factor: ATX
ATX version: 3.0
design
Product color: Black
Cooling: Active
Fan diameter: 13.5cm
Number of fans: 1 fan
Feature: on/off switch
scope of delivery
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Feature: Cable ties included
Weight and dimensions
Width: 150mm
Depth: 150mm
Height: 86mm
Weight: 2.48kg
Packaging data
Packaging width: 310 mm
Packaging depth: 200 mm
Packaging height: 108 mm
Package weight: 3.17 kg
Packaging type: box
Technical details
Feature: Sustainability compliance
Sustainability certificates: RoHS
